Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | GFD563A101 3BHE046836R0101 |
| Manufacturer | ABB |
| Product category | Industrial Ethernet Communication Module |
| Operating voltage | 24 VDC ±10% |
| Power consumption | 10 W typical |
| Ethernet standards | IEEE 802.3 (10BASE-T/100BASE-TX) |
| Data transfer rate | 10/100 Mbps (auto-negotiation) |
| Communication protocols | TCP/IP, UDP, Modbus TCP, PROFINET IO |
| Interface type | 2 x RJ45 ports (M12 optional) |
| Operating temperature | -20°C to +60°C (-4°F to +140°F) |
| Humidity tolerance | 5% to 95% RH (non-condensing) |
| Installation method | DIN rail mount (35mm) or panel mount |
| Dimensions | 100mm × 80mm × 50mm (3.94″ × 3.15″ × 1.97″) |
| Certifications | CE, UL, CUL, ATEX, IECEx |
GFD563A101 3BHE046836R0101
Product introduction
The ABB GFD563A101 3BHE046836R0101 is a high-performance industrial Ethernet communication module designed to serve as a critical connectivity hub in modern automation systems. As part of ABB’s extensive portfolio of industrial communication solutions, this module bridges the gap between field devices and control systems, enabling reliable data exchange in demanding industrial environments.
ABB GFD563A101 3BHE046836R0101 combines robust hardware design with advanced communication capabilities, making it an ideal choice for integrating diverse automation components into unified networks. Its compact form factor belies its powerful functionality, supporting multiple industrial protocols to ensure seamless interoperability with various PLCs, DCS systems, and smart field devices.
In automation architectures, ABB GFD563A101 3BHE046836R0101 plays a pivotal role in enabling real-time data transmission, which is essential for process optimization, condition monitoring, and remote control applications. By providing stable network connectivity even in harsh industrial conditions, this module helps maintain operational continuity and enhances overall system efficiency.
Core advantages and technical highlights
Industrial-grade reliability: ABB GFD563A101 3BHE046836R0101 is engineered to withstand extreme environmental conditions, operating reliably across a wide temperature range from -20°C to +60°C. Its rugged construction includes surge protection and EMI/RFI immunity, ensuring uninterrupted communication even in electrically noisy environments common in manufacturing plants and process facilities. This durability minimizes network downtime and reduces maintenance requirements.
Multi-protocol flexibility: Unlike single-protocol communication modules, ABB GFD563A101 3BHE046836R0101 supports multiple industrial protocols including Modbus TCP and PROFINET IO, in addition to standard TCP/IP and UDP. This versatility allows it to integrate seamlessly into diverse automation ecosystems, eliminating the need for protocol converters and simplifying system architecture. The module’s auto-negotiation capability ensures optimal connection speeds with various network devices.
Advanced diagnostic features: ABB GFD563A101 3BHE046836R0101 incorporates comprehensive built-in diagnostics that provide real-time insights into network performance and device status. Users can monitor link status, data transmission rates, and error counts, enabling proactive identification of potential issues before they affect operations. This diagnostic functionality simplifies troubleshooting and reduces mean time to repair, enhancing overall system availability.
Easy integration and scalability: The compact design of ABB GFD563A101 3BHE046836R0101 facilitates flexible installation in space-constrained control cabinets, while its DIN rail mounting capability ensures quick and secure deployment. The module supports network expansion through its dual Ethernet ports, allowing the creation of redundant network topologies for critical applications requiring high availability. This scalability makes it suitable for both small-scale machines and large industrial complexes.
Typical application scenarios
In chemical processing plants, ABB GFD563A101 3BHE046836R0101 serves as a critical communication node connecting distributed control systems (DCS) with field instruments such as flow meters, pressure transmitters, and analytical sensors. Its robust design withstands the harsh conditions of chemical environments, while its multi-protocol support enables seamless integration with both ABB and third-party automation components. The module’s diagnostic capabilities help maintenance teams quickly identify communication issues in the plant’s extensive sensor network, minimizing process disruptions.
Within automotive manufacturing facilities, ABB GFD563A101 3BHE046836R0101 facilitates real-time data exchange between production line robots, PLCs, and supervisory systems. Its PROFINET IO support ensures deterministic communication essential for synchronized assembly processes, while its rugged construction handles the vibration and electrical noise common in manufacturing environments. The module’s redundant network capability provides fail-safe communication for critical production lines, helping maintain consistent production output.
Water and wastewater treatment plants utilize ABB GFD563A101 3BHE046836R0101 to connect SCADA systems with pumps, valves, and monitoring equipment spread across large facilities. Its wide operating temperature range ensures reliable performance in both outdoor and indoor installations, while Modbus TCP support enables integration with legacy monitoring equipment. The module’s stable data transmission capabilities are crucial for maintaining proper water treatment processes and ensuring regulatory compliance through accurate data logging.
GFD563A101 3BHE046836R0101
Related model recommendations
ABB GFD561A101 3BHE046835R0101: Entry-level Ethernet module with similar form factor, ideal for basic connectivity requirements in smaller automation systems.
ABB GFD565A101 3BHE046837R0101: Advanced version with Gigabit Ethernet support for high-bandwidth applications requiring faster data transmission.
ABB CI854A 3BSE030220R1: Profibus communication module that complements ABB GFD563A101 3BHE046836R0101 in hybrid networks combining Ethernet and Profibus technologies.
ABB XVC762A 3BHE036884R0101: Network switch designed to work with ABB GFD563A101 3BHE046836R0101 for creating larger industrial Ethernet networks with enhanced redundancy.
ABB PM864K01 3BSE018105R1: PLC processor module that integrates seamlessly with ABB GFD563A101 3BHE046836R0101 for complete control and communication solutions.
ABB TU810V1 3BSE013231R1: Terminal unit providing power distribution and signal conditioning when paired with ABB GFD563A101 3BHE046836R0101 in control cabinets.
ABB 800xA AC800M system: Distributed control platform that utilizes ABB GFD563A101 3BHE046836R0101 modules for networked communication between controller nodes.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing ABB GFD563A101 3BHE046836R0101, ensure the mounting location provides adequate ventilation and protection from direct moisture. Verify the power supply meets the 24 VDC ±10% requirement and use a dedicated circuit with appropriate overcurrent protection. Prepare shielded Ethernet cables (Cat 5e or higher) for network connections, ensuring cable lengths do not exceed 100 meters for optimal performance. Use the provided DIN rail clips or panel mounting holes to secure the module, ensuring proper grounding via the module’s earth terminal for electrical noise immunity.
Maintenance suggestions: Perform regular visual inspections of ABB GFD563A101 3BHE046836R0101 to check for loose connections or signs of overheating. Monitor diagnostic data through the connected control system to track network performance metrics and error rates. Clean dust accumulation from ventilation openings quarterly using compressed air. When troubleshooting communication issues, verify power supply stability first, then check cable connections and network configuration parameters. For firmware updates, use ABB’s recommended software tools and follow proper update procedures during scheduled maintenance windows to avoid operational disruptions. Replace any damaged Ethernet ports or connectors promptly to maintain network integrity.
Service and guarantee commitment
ABB stands behind the quality and reliability of ABB GFD563A101 3BHE046836R0101 with a comprehensive 36-month warranty covering manufacturing defects and performance issues under normal operating conditions. Our global network of technical support centers provides expert assistance for installation, configuration, and troubleshooting needs, ensuring quick resolution of any issues that may arise.
Customers receive access to ABB’s extensive knowledge base, including detailed documentation, application notes, and software updates to maximize the module’s performance throughout its operational lifecycle. Beyond the warranty period, ABB offers flexible service agreements tailored to specific operational requirements, including preventive maintenance, calibration verification, and expedited replacement services. With ABB’s commitment to excellence, users of ABB GFD563A101 3BHE046836R0101 can expect reliable performance and comprehensive support for their industrial communication needs.
