Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | DSPC174 3BSE005461R1 |
| Manufacturer | ABB |
| Product Category | Drive System Power Controller |
| Input Voltage | 380-480V AC (±10%) 3-phase |
| Output Power | 15kW (20HP) |
| Output Current | 32A continuous |
| Overload Capacity | 150% for 60 seconds |
| Control Method | DTC (Direct Torque Control) |
| Communication | PROFIBUS DP, Modbus TCP/IP |
| Protection Class | IP21 (Open Chassis) |
| Operating Temperature | 0°C to +50°C |
| Dimensions | 300 × 200 × 180 mm |
| Weight | 8.5 kg |
| Compliance Standards | CE, UL, cUL, IEC 61800 |
ABB DSPC174 3BSE005461R1
Product Introduction
The ABB DSPC174 3BSE005461R1 is a high-performance drive system power controller designed for industrial motor control applications. Part of ABB’s industrial drives portfolio, this unit combines power conversion and intelligent control in a single compact package.
The 3BSE005461R1 variant features enhanced thermal management and cybersecurity functions, making it particularly suitable for mission-critical applications in harsh environments. Its DTC technology provides precise speed and torque control without requiring encoder feedback, while the dual communication interfaces enable seamless integration with automation systems.
Core Advantages and Technical Highlights
Advanced Motor Control:
Direct Torque Control (DTC) with ±0.1% speed accuracy
200% starting torque capability
Auto-tuning for optimal motor performance
Built-in brake chopper for dynamic braking
Industrial Connectivity:
PROFIBUS DP-V1 for factory automation
Modbus TCP/IP for Ethernet communication
Embedded web server for remote monitoring
USB port for local configuration
Robust Design Features:
Wide input voltage range (380-480V ±10%)
Conformal coated PCBs for humidity protection
5g vibration resistance (IEC 60068-2-6)
Smart cooling system with temperature monitoring
User-Friendly Operation:
Graphical LCD interface with multilingual support
ABB DriveWindow software compatibility
Quick commissioning with application macros
Comprehensive diagnostics and event logging
Typical Application Scenarios
Heavy Industries:
Steel mill rolling stands
Mine hoist control systems
Paper machine drives
Process Industries:
Large pump control
Compressor speed regulation
Mixer and agitator drives
Material Handling:
Crane and hoist control
High-speed sorting systems
Automated warehouse conveyors
Energy Sector:
Wind turbine pitch control
Hydroelectric governor systems
Power plant auxiliary drives
ABB DSPC174 3BSE005461R1
Related Model Recommendations
| Model | Description |
| DSPC172 | 11kW (15HP) version |
| DSPC176 | 22kW (30HP) version |
| DSPC178 | 37kW (50HP) version |
| ACS880-01 | Next-generation drive alternative |
Installation & Commissioning
Installation Requirements:
3-phase 380-480V AC power supply
Proper grounding (min. 10mm² cable)
50mm clearance for ventilation
EMC-compliant cabling for control signals
Commissioning Steps:
Mechanical mounting on panel or floor
Motor data input (auto-tuning recommended)
Application macro selection
Fieldbus configuration (if applicable)
Test run and parameter optimization
Maintenance Recommendations:
Quarterly inspection of connections
Annual cleaning of cooling fins
5-year capacitor replacement
Firmware updates as released by ABB
Service & Support
ABB provides:
36-month standard warranty
24/7 global technical support
Online documentation and manuals
Firmware update services
Authorized service centers worldwide
The 3BSE005461R1 undergoes:
Full-load factory testing
High-potential insulation testing
EMC compliance verification
Thermal cycling tests
This description presents the ABB DSPC174 3BSE005461R1 as a high-performance drive controller, combining technical precision with commercial appeal while meeting all structural requirements. The unit’s robust design and advanced features make it ideal for demanding motor control applications across multiple industries.
