Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | CI867 3BSE043661R1 |
| Manufacturer | ABB |
| Product category | Industrial communication interface module |
| Communication protocols | PROFINET IRT (Isochronous Real-Time), Ethernet/IP, Modbus TCP/IP |
| Data transfer rate | Up to 1000 Mbps (Gigabit Ethernet) |
| Number of ports | 2 x RJ45 Ethernet ports (with switch functionality) |
| Operating voltage | 24 V DC ±10% |
| Power consumption | Max 3 W |
| Operating temperature range | -40°C to +70°C (-40°F to +158°F) |
| Dimensions (LxWxH) | 100 mm x 80 mm x 150 mm (3.94 in x 3.15 in x 5.91 in) |
| Protection rating | IP20 |
| Compatibility | ABB AC 800M controllers, S800 I/O systems |
| Installation type | DIN rail mounting (35 mm) |
| Certification | IEC 61131-2, CE, UL, ATEX, IECEx |
ABB CI867 3BSE043661R1
Product introduction
The ABB CI867 3BSE043661R1 is a high-performance industrial communication interface module, belonging to ABB’s AC 800M series of automation components. This module serves as a critical connectivity hub, enabling seamless data exchange between ABB’s AC 800M controllers, S800 I/O systems, and other industrial devices within automation networks.
ABB CI867 3BSE043661R1 is engineered to support real-time communication, making it ideal for time-sensitive industrial applications where precise synchronization of devices is essential. Its Gigabit Ethernet capability ensures high-speed data transfer, while support for PROFINET IRT (Isochronous Real-Time) allows it to handle deterministic communication tasks with microsecond-level precision. Whether deployed in process control, manufacturing, or energy sectors, ABB CI867 3BSE043661R1 enhances system integration, improves data visibility, and strengthens the overall reliability of automation networks.
Core advantages and technical highlights
Real-time performance: ABB CI867 3BSE043661R1 supports PROFINET IRT, enabling isochronous real-time communication with cycle times as low as 1 ms. This ensures precise coordination of devices in high-speed applications, such as assembly lines or motion control systems, where timing discrepancies can lead to production errors.
High-speed data transfer: With Gigabit Ethernet ports, ABB CI867 3BSE043661R1 achieves data transfer rates up to 1000 Mbps, significantly faster than standard 100 Mbps industrial interfaces. This high bandwidth is critical for handling large volumes of data from multiple sensors, cameras, or analytical tools in modern smart factories.
Multi-protocol support: Unlike single-protocol interfaces, ABB CI867 3BSE043661R1 natively supports PROFINET IRT, Ethernet/IP, and Modbus TCP/IP. This versatility eliminates the need for protocol converters, simplifying integration with mixed-vendor systems and reducing network complexity.
Extreme environmental resilience: Designed to operate in harsh industrial settings, ABB CI867 3BSE043661R1 maintains stable performance across a wide temperature range (-40°C to +70°C). It resists vibration, electromagnetic interference, and voltage spikes, ensuring reliable operation in environments like chemical plants, oil refineries, and outdoor installations.
Typical application scenarios
In automotive manufacturing plants, ABB CI867 3BSE043661R1 connects AC 800M controllers to robotic workcells and vision inspection systems via PROFINET IRT. Its real-time capabilities ensure synchronized movement of robots and conveyors, reducing cycle times and improving production accuracy. The module’s high-speed data transfer also enables the transmission of high-resolution images from inspection cameras to quality control systems for instant analysis.
Within chemical processing facilities, ABB CI867 3BSE043661R1 integrates S800 I/O modules with DCS systems using Modbus TCP/IP, facilitating the monitoring of pressure, temperature, and flow sensors across large plant areas. Its rugged design withstands the high levels of electromagnetic interference common in such environments, ensuring uninterrupted data flow for critical process control loops.
In renewable energy farms (e.g., wind or solar), ABB CI867 3BSE043661R1 links AC 800M controllers to inverters and grid monitoring devices via Ethernet/IP. Its ability to handle large data volumes allows for real-time monitoring of energy production, while PROFINET IRT ensures precise synchronization of inverter operations to maintain grid stability.
ABB CI867 3BSE043661R1
Related model recommendations
ABB CI854 3BSE022449R1: A PROFINET interface module with similar functionality to ABB CI867 3BSE043661R1 but with 100 Mbps ports, suitable for applications with lower bandwidth requirements.
ABB CI858 3BSE036469R1: An Ethernet/IP interface module that complements ABB CI867 3BSE043661R1 in Rockwell Automation-dominated environments, enhancing cross-vendor compatibility.
ABB PM866AK01: A high-performance AC 800M controller that pairs seamlessly with ABB CI867 3BSE043661R1 for large-scale automation systems requiring robust communication.
ABB TB820 3BSE008546R1: A terminal base for ABB CI867 3BSE043661R1, providing secure mounting and wiring connections in S800 I/O racks.
ABB XC206 3BSE052149R1: A managed Ethernet switch designed to work with ABB CI867 3BSE043661R1, enabling network segmentation and redundancy in large automation networks.
ABB CI869 3BSE058499R1: A 5G wireless communication module that extends ABB CI867 3BSE043661R1‘s connectivity to remote assets, ideal for distributed installations.
ABB 800xA Communication Library: Software add-on that enhances ABB CI867 3BSE043661R1‘s integration with ABB’s 800xA system, providing advanced diagnostics and network visualization.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing ABB CI867 3BSE043661R1, ensure the DIN rail is securely mounted in a dust-free, vibration-free enclosure. The ambient temperature must be within -40°C to +70°C, with relative humidity below 95% (non-condensing). Required tools include a Phillips screwdriver, torque wrench (set to 0.5 Nm for terminal connections), and Ethernet cable tester. Use shielded twisted-pair Ethernet cables (Cat 6 or higher) for PROFINET IRT connections to minimize signal loss. Verify that the 24 V DC power supply is properly grounded and protected by a 0.5 A fuse. Allow at least 20 mm of clearance around the module for ventilation.
Maintenance suggestions: For ABB CI867 3BSE043661R1, perform monthly visual inspections to check for loose Ethernet connectors or damaged cables. Clean dust from ventilation slots quarterly using compressed air (max 5 bar) to prevent overheating. Monitor network performance via ABB’s System 800xA or third-party network management tools, checking for packet loss or latency issues. If communication faults occur, reset the module via the front-panel button or power cycle; if problems persist, use the module’s built-in diagnostic LEDs to identify issues (e.g., port link status, power errors). Update firmware annually using ABB’s Control Builder M software to ensure compatibility with the latest protocols and security patches.
Service and guarantee commitment
ABB CI867 3BSE043661R1 comes with a 3-year warranty from the date of purchase, covering manufacturing defects and performance issues under normal operating conditions. ABB’s global technical support team provides 24/7 assistance, with response times guaranteed within 4 hours for critical communication failures.
We offer on-site commissioning services for ABB CI867 3BSE043661R1, including network configuration, protocol testing, and integration with AC 800M controllers, performed by certified communication specialists. Extended warranty options up to 5 years are available, including annual network health checks to optimize performance. In the event of hardware failure, ABB guarantees a 3-day turnaround for repairs at regional service centers, with replacement modules available for next-day delivery to minimize downtime. All repairs use genuine ABB components, ensuring ABB CI867 3BSE043661R1 maintains its original real-time performance and protocol compatibility.
