Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB AI810 3BSE008516R1 |
| Manufacturer | ABB |
| Product Category | Analog Input Module |
| Input Channels | 8 channels |
| Input Signal Range | 0–20 mA, 4–20 mA, ±10 V, 0–10 V |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-channel and channel-to-system |
| Communication Interface | S800 I/O Bus (ABB Advant/AC 800M) |
| Power Supply | 24V DC (via backplane) |
| Operating Temperature | 0°C to +60°C |
| Protection Rating | IP20 (panel-mounted) |
ABB AI810 3BSE008516R1
Product Introduction
The ABB AI810 3BSE008516R1 is a high-precision 8-channel analog input module designed for industrial automation and process control systems. Part of ABB’s S800 I/O family, it seamlessly integrates with ABB Advant Controller 800M and AC 800M DCS/PLC systems, providing reliable signal conditioning for critical process measurements.
Engineered for flexibility, the ABB AI810 3BSE008516R1 supports multiple input types, including current (0–20 mA, 4–20 mA) and voltage (±10 V, 0–10 V), making it ideal for interfacing with sensors, transmitters, and other field devices. Its robust design ensures stable performance in harsh industrial environments, while 16-bit resolution guarantees precise data acquisition for process optimization.
Core Advantages and Technical Highlights
High accuracy and stability: The ABB AI810 3BSE008516R1 delivers ±0.1% accuracy, ensuring reliable signal conversion for critical process monitoring. Its 16-bit resolution minimizes quantization errors, making it suitable for high-precision applications like chemical dosing and temperature control.
Advanced isolation: Featuring channel-to-channel and channel-to-system isolation, the module prevents ground loops and electrical noise interference, enhancing signal integrity in electrically noisy environments.
Wide compatibility: Designed for ABB’s S800 I/O system, the ABB AI810 3BSE008516R1 integrates smoothly with AC 800M controllers, reducing configuration complexity. Its modular design allows easy expansion, supporting scalable automation solutions.
Robust construction: With an operating temperature range of 0°C to +60°C and IP20 protection, the module withstands industrial conditions, ensuring long-term reliability in manufacturing, energy, and process industries.
Typical Application Scenarios
The ABB AI810 3BSE008516R1 is widely used in industries requiring precise analog signal acquisition:
Process industries: In oil & gas refineries, the module interfaces with pressure transmitters and flow meters, enabling real-time monitoring of pipeline conditions. Its high accuracy ensures compliance with safety and efficiency standards.
Power generation: The module integrates with turbine control systems, collecting analog signals from vibration sensors and temperature probes to prevent equipment failures.
Water treatment plants: The ABB AI810 3BSE008516R1 monitors pH levels, turbidity, and chemical dosing rates, optimizing treatment processes while minimizing manual intervention.
ABB AI810 3BSE008516R1
Related Model Recommendations
ABB AO810 3BSE008517R1: Analog output module, complements AI810 for closed-loop control.
ABB DI810 3BSE008510R1: Digital input module, ideal for integrating discrete signals.
ABB CI854 3BSE018105R1: Communication interface for linking S800 I/O with higher-level controllers.
ABB PM864AK1: Processor module for AC 800M, enhances system performance.
ABB TA810 3BSE013234R1: Terminal unit for easy wiring of AI810 modules.
Installation, Commissioning, and Maintenance Instructions
Installation preparation: Ensure the ABB AI810 3BSE008516R1 is mounted on a compatible S800 baseplate in a well-ventilated enclosure. Verify power supply stability (24V DC) and use shielded cables for analog inputs to reduce noise.
Maintenance suggestions: Periodically check terminal connections for corrosion and verify calibration using ABB’s Composer or Control Builder tools. Replace the module if drift exceeds ±0.2% full scale.
Service and Guarantee Commitment
ABB guarantees the ABB AI810 3BSE008516R1 for 24 months from delivery, covering defects in materials and workmanship. Global technical support is available via ABB’s service network, with on-site assistance for critical failures. Firmware updates and configuration guides are accessible through ABB’s MyControlSystem portal.
