Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB AI810 3BSE008516R1 |
| Manufacturer | ABB |
| Product Category | Analog Input Module |
| Channels | 8 channels |
| Input Signal Range | 0-20 mA, 4-20 mA, ±10 V, RTD, Thermocouple (configurable) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Sampling Rate | Up to 100 samples/sec per channel |
| Isolation | Channel-to-channel & field-to-logic |
| Power Supply | 24 V DC (via backplane) |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP20 |
| Compatible Systems | ABB AC800M, Advant OCS, S800 I/O |
ABB AI810 3BSE008516R1
Product Introduction
The ABB AI810 3BSE008516R1 is a high-performance 8-channel analog input module designed for precision signal acquisition in industrial automation and process control systems. Part of ABB’s S800 I/O series, this module seamlessly integrates with ABB AC800M PLCs and Advant OCS DCS, providing reliable data acquisition for critical process variables such as temperature, pressure, and flow.
Engineered for demanding industrial environments, the AI810 3BSE008516R1 supports multiple input types, including current (4-20 mA, 0-20 mA), voltage (±10 V), RTD (Pt100, Pt1000), and thermocouples (J, K, T, etc.). Its 16-bit resolution and ±0.1% accuracy ensure high-fidelity signal conversion, making it ideal for applications requiring precise monitoring and control.
Core Advantages and Technical Highlights
Universal Input Flexibility: The ABB AI810 3BSE008516R1 supports a wide range of analog signals, eliminating the need for separate modules for different sensor types. Each channel is independently configurable via software.
High Accuracy & Stability: With 16-bit resolution and ±0.1% accuracy, the module delivers reliable measurements even in electrically noisy environments. Advanced filtering minimizes signal drift.
Robust Isolation & Noise Immunity: Galvanic isolation between channels and field-to-logic circuits prevents ground loops and ensures stable operation in harsh conditions.
Fast Sampling & Real-Time Processing: The module samples at 100 samples/sec per channel, enabling real-time monitoring for dynamic control applications.
Seamless Integration: The AI810 3BSE008516R1 connects via the ABB S800 I/O bus, ensuring plug-and-play compatibility with AC800M and Advant OCS systems.
Wide Temperature Range: Operates reliably from -25°C to +70°C, making it suitable for extreme industrial environments.
Typical Application Scenarios
The ABB AI810 3BSE008516R1 is widely used in industries requiring high-precision analog signal acquisition:
Oil & Gas: Monitoring pressure, temperature, and flow in pipelines and refineries.
Power Generation: Measuring turbine vibrations, coolant temperatures, and grid parameters.
Chemical Processing: Precise control of reactor temperatures and chemical dosing.
Water & Wastewater: Level and pH monitoring in treatment plants.
Manufacturing: Quality control via sensor feedback in automated production lines.
Its rugged design ensures long-term reliability in high-vibration and corrosive environments.
ABB AI810 3BSE008516R1
Related Model Recommendations
ABB AO810 (3BSE008517R1) – 8-channel analog output module, ideal for closed-loop control.
ABB DI810 (3BSE008512R1) – 16-channel digital input module for status monitoring.
ABB DO810 (3BSE008513R1) – 16-channel digital output module for actuator control.
ABB CI854 (3BSE018144R1) – Communication interface for PROFIBUS DP integration.
ABB PM856 (3BSE018105R1) – Redundant power supply module for critical systems.
These modules form a complete ABB S800 I/O solution for industrial automation.
Installation, Commissioning & Maintenance
Installation Preparation:
Mount the ABB AI810 3BSE008516R1 on a DIN rail or S800 I/O baseplate.
Ensure proper grounding and use shielded cables for analog signals.
Verify power supply stability (24V DC) before powering up.
Maintenance Suggestions:
Periodically verify calibration using ABB Control Builder software.
Inspect terminals for corrosion or loose connections.
Replace modules only when the system is powered off.
Service and Guarantee Commitment
ABB provides a 24-month warranty for the AI810 3BSE008516R1, covering manufacturing defects. Global technical support is available for troubleshooting, and firmware updates are provided through ABB’s official channels. Customized training ensures optimal deployment in complex automation systems.
