Description
Detailed parameter table
| Parameter name | Parameter value |
| Product model | 3BHE024577R0101 PPC907BEAMC34 |
| Manufacturer | ABB |
| Product category | Processor module (part of Symphony Plus system) |
| Processor | 32-bit RISC processor (1 GHz) |
| Memory | 2 GB RAM, 8 GB flash storage |
| Operating system | VxWorks real-time operating system |
| Communication interfaces | 2 x Ethernet (10/100/1000 Mbps), 1 x Profibus DP, 1 x RS-232 |
| I/O capacity | Up to 4096 digital inputs/outputs, 1024 analog inputs/outputs |
| Redundancy support | 1:1 hot standby |
| Operating temperature | 0°C to 55°C |
| Storage temperature | -40°C to 85°C |
| Humidity tolerance | 5 – 95% RH (non-condensing) |
| Mounting type | Rack mount (3U height, 19-inch rack) |
| Dimensions | 132mm (height) x 483mm (width) x 280mm (depth) |
| Certifications | CE, UL, cUL, IECEx |
| Power supply | 24 VDC ±10%, 25 W max |
ABB 3BHE024577R0101 PPC907BEAMC34
Product introduction
The ABB 3BHE024577R0101 PPC907BEAMC34 is a high-performance processor module, serving as the core of ABB’s Symphony Plus distributed control system (DCS). It is engineered to execute complex control algorithms, process real-time data from various I/O modules, and coordinate the operation of industrial processes.
With a powerful 32-bit RISC processor and ample memory, this module can handle large amounts of data and complex control tasks with high efficiency. Its support for redundancy ensures uninterrupted operation, making it suitable for critical industrial applications where downtime is not acceptable. The ABB 3BHE024577R0101 PPC907BEAMC34 plays a pivotal role in enabling the Symphony Plus system to provide precise control, reliable monitoring, and efficient management of industrial processes.
Core advantages and technical highlights
High processing performance: Equipped with a 1 GHz 32-bit RISC processor and 2 GB RAM, the ABB 3BHE024577R0101 PPC907BEAMC34 delivers exceptional processing power. It can quickly execute complex control logic, such as PID algorithms with advanced tuning, and process large volumes of real-time data from I/O modules. In a large-scale chemical plant with thousands of process variables, this high performance ensures that control actions are calculated and executed in a timely manner, maintaining stable process operation.
Redundancy support: The module supports 1:1 hot standby redundancy, where a backup module continuously monitors the primary module. In the event of a primary module failure, the backup module seamlessly takes over without interrupting the process. This redundancy feature is critical in applications such as power generation, where any interruption in control could lead to significant losses or safety hazards.
Flexible communication: With multiple communication interfaces, including Ethernet and Profibus DP, the ABB 3BHE024577R0101 PPC907BEAMC34 can easily integrate with various I/O modules, HMI panels, and other system components. The Ethernet interface enables high-speed data transmission with upper-level systems, such as MES (Manufacturing Execution Systems) or ERP (Enterprise Resource Planning) systems, facilitating data exchange and process optimization.
Large I/O capacity: Supporting up to 4096 digital inputs/outputs and 1024 analog inputs/outputs, the module can handle the needs of large industrial systems. This large capacity eliminates the need for multiple processor modules in complex applications, simplifying the system architecture and reducing maintenance complexity. For example, in a large oil refinery with numerous sensors and actuators, this module can effectively manage all I/O signals.
Typical application scenarios
In power generation plants, the ABB 3BHE024577R0101 PPC907BEAMC34 is used to control and monitor boiler, turbine, and generator systems. It processes data from pressure, temperature, and flow sensors, executes control algorithms to adjust fuel supply and steam flow, and ensures stable power output. The redundancy feature guarantees continuous operation, preventing power outages due to module failures.
Within oil and gas refineries, the module is integrated into the Symphony Plus system to control distillation columns, catalytic crackers, and other key process units. It coordinates the operation of various valves, pumps, and heaters based on input from process sensors, optimizing product quality and production efficiency. The large I/O capacity allows it to handle the numerous signals from the complex refinery processes.
In chemical processing plants, the ABB 3BHE024577R0101 PPC907BEAMC34 manages batch and continuous processes, ensuring precise control of reaction conditions such as temperature, pressure, and chemical composition. It communicates with HMI panels to provide operators with real-time process data and alarm information, enabling timely adjustments and ensuring safe operation.
ABB 3BHE024577R0101 PPC907BEAMC34
Related model recommendations
ABB 3BHE024578R0101 PPC907BEAMC35: A higher-performance variant with a 1.5 GHz processor and 4 GB RAM, suitable for more complex control tasks.
ABB CI854A 3BSE022469R1: A Profibus DP communication module that expands the communication capabilities of the ABB 3BHE024577R0101 PPC907BEAMC34 in distributed systems.
ABB 800xA HMI: A human-machine interface that works with the processor module, providing operators with a visual representation of the process and allowing for manual control.
ABB DSDP140B 57160001-ACX: A digital input module that connects to field sensors and transmits data to the ABB 3BHE024577R0101 PPC907BEAMC34 for processing.
ABB DSOP140B 57160002-ACX: A digital output module that receives control signals from the processor module and controls actuators and valves.
ABB PPD513A0E110110 3BHE039724R0E41: A power distribution module that provides reliable power to the processor module and other system components.
Installation, commissioning and maintenance instructions
Installation preparation: Before installing the ABB 3BHE024577R0101 PPC907BEAMC34, ensure the 19-inch rack is securely mounted and properly grounded. Verify that the operating environment meets the temperature and humidity requirements. Gather necessary tools, including screwdrivers, torque wrench, and a multimeter. Check that the 24 VDC power supply is stable and fused appropriately. Plan the wiring for communication interfaces and power connections, ensuring proper cable routing to avoid interference.
Commissioning steps: After mounting the module in the rack, connect the power supply and communication cables. Power on the module and check the status indicators to confirm it is initializing correctly. Use the Symphony Plus configuration software to load the control program and configure communication parameters. Test the redundancy function by simulating a primary module failure and verifying that the backup module takes over seamlessly. Calibrate the I/O modules connected to the processor module to ensure accurate data acquisition and control.
Maintenance suggestions: Inspect the ABB 3BHE024577R0101 PPC907BEAMC34 quarterly for loose connections, dust accumulation, or signs of overheating. Clean the module’s vents with compressed air to ensure proper cooling. Monitor the status indicators and system logs regularly to detect any potential issues. Perform regular backups of the control program and configuration data to prevent data loss. If a fault is detected, first check the power supply and communication connections; if the issue persists, replace the module with a redundant unit or an ABB-approved spare part.
Service and guarantee commitment
The ABB 3BHE024577R0101 PPC907BEAMC34 comes with a 36-month warranty from the date of purchase, covering manufacturing defects and ensuring compliance with published specifications. In case of a confirmed fault within this period, ABB will replace the module free of charge, with a guarantee of delivery within 48 hours for critical applications to minimize downtime.
ABB provides comprehensive technical support, including access to a global team of engineers via phone and email. Online resources such as installation manuals, programming guides, and troubleshooting documents are available to assist with any issues. Customers can also utilize ABB’s local service centers for on-site support during installation, commissioning, and maintenance. Optional extended service contracts offer preventive maintenance, priority technical support, and software updates, ensuring the module operates reliably throughout its 15-year design lifespan.
