Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB 3BHE006373R0101 XVC769AE101 |
| Manufacturer | ABB |
| Product Category | Voltage Control Module |
| Input Voltage Range | 85-264V AC, 47-63Hz |
| Output Voltage | 24V DC (±0.5%) |
| Rated Current | 20A continuous |
| Peak Current Capacity | 30A (for 5 seconds) |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP20 (standard), IP65 (optional) |
| Mounting Type | DIN Rail or panel mount |
| Dimensions | 145mm × 125mm × 85mm |
| Communication Protocols | PROFINET, EtherNet/IP, Modbus TCP |
| Efficiency | >94% |
| MTBF | >500,000 hours |
| Certifications | UL 508, CE, IEC 61800-5-1 |
ABB 3BHE006373R0101 XVC769AE101
Product Introduction
The ABB 3BHE006373R0101 XVC769AE101 represents the pinnacle of industrial power conversion technology, delivering ultra-stable 24V DC power for mission-critical automation systems. As part of ABB’s premium XVC-700 series, this advanced voltage control module sets new standards for precision, reliability, and connectivity in industrial power management.
Designed specifically for integration with ABB’s 800xA Distributed Control System and AC 800M controllers, the XVC769AE101 combines military-grade components with intelligent power management features. Its exceptional ±0.5% voltage regulation accuracy ensures perfect power conditions for sensitive automation equipment, even in the most demanding industrial environments.
Core Advantages and Technical Highlights
Military-Grade Precision:
The ABB XVC769AE101 delivers unprecedented ±0.5% voltage regulation accuracy, maintaining perfect power conditions for sensitive measurement and control electronics regardless of input fluctuations.
Extreme Environment Performance:
With an extended operating range of -40°C to +85°C, this module continues operating reliably in conditions that would cause conventional power supplies to fail.
Intelligent Power Management:
Advanced features include:
Active current sharing for parallel operation
Predictive failure detection
Load-dependent fan control
Real-time power consumption monitoring
Future-Proof Connectivity:
Triple-redundant communication interfaces (PROFINET, EtherNet/IP, Modbus TCP) enable seamless integration into Industry 4.0 architectures and digital twin implementations.
Unmatched Reliability:
With MTBF exceeding 500,000 hours and military-grade components, the XVC769AE101 is engineered for continuous operation in 24/7 critical processes.
Typical Application Scenarios
The ABB 3BHE006373R0101 XVC769AE101 is indispensable in applications where power reliability directly impacts safety and profitability:
Nuclear Power Plants: Safety-critical instrumentation power
Offshore Oil Platforms: Harsh environment process control
Pharmaceutical Manufacturing: cGMP-compliant cleanroom automation
Data Center Infrastructure: Industrial control system power
Military Installations: Secure facility automation systems
Its combination of precision, ruggedness, and smart features makes it particularly valuable in applications where power quality directly impacts process outcomes or safety systems.
ABB 3BHE006373R0101 XVC769AE101
Related Model Recommendations
ABB XVC769RE101 – Fully redundant version with hot-swap capability
ABB XVC767AE101 – 10A output version for less demanding applications
ABB XVC780AE101 – 40A high-density version
ABB PPD115 – Intelligent power distribution unit
ABB CMA145 – Advanced communication gateway
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
The XVC769AE101 requires professional installation by qualified personnel. Ensure proper ventilation (minimum 100mm clearance above/below) and verify all electrical parameters before energizing. Use ABB-recommended circuit protection devices for optimal performance.
Maintenance Protocol:
While designed for maintenance-free operation, we recommend:
Quarterly thermal imaging scans
Annual firmware updates via ABB Automation Builder
Biannual cleaning of cooling fins
Continuous monitoring via integrated web server interface
Service and Guarantee Commitment
ABB backs the 3BHE006373R0101 XVC769AE101 with an industry-leading 60-month warranty, including advanced replacement service. Our global network of power specialists provides 24/7 technical support with guaranteed 4-hour response for critical applications. The product includes ABB’s Lifetime Service program, ensuring ongoing support and component availability throughout its operational life.
