ABB 3BHB030310R0001

Description

Detailed parameter table

ABB 3BHB030310R0001

Product introduction

The ABB 3BHB030310R0001 is a compact, high-reliability power supply module designed to deliver stable 24 VDC power to critical components in industrial control systems, including PLC modules, sensors, and small actuators. As part of ABB’s extensive lineup of industrial power solutions, the 3BHB030310R0001 combines robust design with precise voltage regulation to ensure uninterrupted operation in demanding industrial environments.

This 5 A module accepts a wide input voltage range (115/230 VAC), making it suitable for global installations without manual voltage adjustment. In automation setups, the ABB 3BHB030310R0001 acts as a dedicated power source for low-voltage control circuits, protecting sensitive electronics from mains voltage fluctuations. Its compact form factor allows easy integration into crowded control cabinets, while built-in protection features safeguard both the module and connected devices—making it a trusted choice for applications where downtime is costly.

Core advantages and technical highlights

Universal input capability: The ABB 3BHB030310R0001 automatically adapts to 115 VAC or 230 VAC input, eliminating the need for voltage selection switches. This feature simplifies global deployment, whether installed in a 115 VAC facility in North America or a 230 VAC plant in Europe. For multinational manufacturers with standardized equipment, the 3BHB030310R0001 ensures consistent power performance across all production sites, reducing inventory complexity.

Stable output with low ripple: Delivering a regulated 24 VDC output with ripple voltage ≤ 100 mV p-p, the ABB 3BHB030310R0001 protects sensitive electronics from noise-induced errors. In precision applications like laboratory automation or semiconductor manufacturing, this stable output prevents data corruption in sensor signals and ensures accurate PLC operation. Even under varying load conditions (10-100% of rated current), the module maintains output voltage within ±2% of setpoint, critical for consistent actuator performance.

Robust protection mechanisms: The ABB 3BHB030310R0001 incorporates comprehensive protection features to enhance system reliability. Overload protection handles temporary current spikes (e.g., during motor startup), while short circuit protection prevents damage from wiring faults. Unlike fuse-based systems, the 3BHB030310R0001 automatically recovers once the fault is resolved, reducing downtime in non-critical faults. This self-healing capability is particularly valuable in remote installations where manual resetting is impractical.

Space-efficient design: With dimensions of 125 mm x 80 mm x 65 mm, the ABB 3BHB030310R0001 occupies minimal space in control cabinets, freeing up room for other components. Its DIN rail mounting allows quick installation and easy reconfiguration, ideal for modular control systems. In compact setups like mobile machinery control panels or small-scale automation cells, this space efficiency ensures the module can be integrated without sacrificing functionality.

Typical application scenarios

In packaging machinery, the ABB 3BHB030310R0001 powers critical control components such as photoelectric sensors, solenoid valves, and PLC I/O modules. During high-speed packaging operations, it delivers stable power to sensors that detect package alignment, ensuring accurate sealing and labeling. If a sudden short circuit occurs in a valve coil, the module’s hiccup-mode protection limits current, preventing damage to the power supply while allowing the system to resume operation once the fault is cleared—minimizing production interruptions.

Water treatment plants utilize the ABB 3BHB030310R0001 to power level sensors and small pump controllers in filtration systems. Installed in control cabinets near chemical dosing stations, the module withstands moderate temperature fluctuations and resistive loads from sensor circuits. Its stable 24 VDC output ensures accurate level readings in filtration tanks, enabling precise control of backwash cycles. The module’s wide input range also accommodates voltage variations common in remote plant locations with unstable mains power.

In factory automation cells, the ABB 3BHB030310R0001 serves as a dedicated power source for safety relays and emergency stop circuits. It provides isolated 24 VDC to ensure safety circuits remain operational even if other power supplies in the system fail. During a safety shutdown, the module maintains stable power to relays, ensuring proper actuation of emergency stops and preventing unexpected machine restart—critical for operator safety in high-risk environments like metalworking cells.

ABB 3BHB030310R0001

Related model recommendations

3BHB030311R0001: A 10 A variant of the 3BHB030310R0001, offering double the current capacity for larger control systems with more devices.

3BHB030309R0001: A lower-power (2 A) version, ideal for small-scale applications like standalone sensors or micro-PLCs.

CI854A: ABB’s Profibus DP communication module, often powered by the 3BHB030310R0001 in distributed control systems.

DI810: A digital input module from ABB’s S800 I/O family, compatible with the 3BHB030310R0001 for signal conditioning in industrial control loops.

TB820: A terminal block accessory that simplifies wiring between the 3BHB030310R0001 and connected devices, providing surge protection.

3BHB030312R0001: A redundant power supply kit containing two 3BHB030310R0001 modules and a redundancy module, ensuring uninterrupted power in mission-critical systems.

PSU860: ABB’s advanced power supply unit with higher efficiency (≥90%), compatible with the 3BHB030310R0001 in hybrid systems requiring both basic and high-performance power sources.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the ABB 3BHB030310R0001, verify the input voltage matches the mains supply (115 or 230 VAC). Ensure the DIN rail is clean, securely mounted, and free from debris. Use insulated tools and anti-static precautions when handling the module to prevent ESD damage. Connect input wiring (16-24 AWG) to the L/N terminals, ensuring proper grounding to the PE terminal. Allow at least 30 mm of clearance above and below for ventilation, as the module dissipates heat through convection.

Maintenance suggestions: Inspect the ABB 3BHB030310R0001 quarterly for loose connections, dust buildup, or signs of overheating (discolored components). Clean dust with compressed air (max 5 bar) to maintain cooling efficiency. Measure output voltage periodically using a calibrated multimeter—deviations beyond ±2% of 24 VDC indicate a potential issue. If the module enters protection mode, identify and resolve the root cause (e.g., shorted load, overload) before resetting. Replace with genuine ABB spare parts if faults persist, ensuring compatibility and maintaining safety certifications.

Service and guarantee commitment

ABB backs the 3BHB030310R0001 with a 12-month warranty covering defects in materials and workmanship. This warranty includes free technical support from ABB’s global service network, with responsive assistance for installation issues or troubleshooting. Customers benefit from access to online resources, including installation manuals and application notes, to optimize module performance.

For critical applications, ABB offers optional extended warranties (up to 3 years) and on-site support services. The company ensures spare parts availability for at least 5 years post-production, minimizing long-term maintenance challenges. With a focus on customer uptime, ABB’s technical team provides timely guidance to resolve issues, reflecting confidence in the 3BHB030310R0001’s reliability and commitment to industrial customers’ success.
