Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 2GUS031803A9 |
| Manufacturer | ABB |
| Product Category | DC Power Module |
| Input Voltage Range | 115 V AC or 230 V AC |
| Output Voltage | 48 V DC |
| Output Current | 6.25 A |
| Power Rating | 300 W |
| Efficiency | Up to 96% |
| Operating Temperature Range | -20°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (W×H×D) | 175 mm × 87 mm × 43 mm |
| Weight | 1.8 kg |
| Protection Level | IP20 |
| Certifications | CE, RoHS |
2GUS031803A9
Product Introduction
The ABB 2GUS031803A9 is a high-performance DC power module designed for industrial automation systems. It is part of ABB’s family of power electronics and is specifically designed to drive PLC system automation equipment. This module converts digital signals into switch output signals and relays them to external devices.
Core Advantages and Technical Highlights
High Efficiency: The 2GUS031803A9 features an efficiency of up to 96%, significantly reducing energy costs and carbon emissions.
High Reliability: The module is designed with fault protection capabilities to minimize downtime and ensure stable system operation.
Compact Design: The module has a compact form factor, making it easy to install and integrate into existing systems.
Wide Operating Temperature Range: The 2GUS031803A9 operates reliably within a temperature range of -20°C to +70°C, making it suitable for various industrial environments.
Multiple Protection Functions: The module includes overheat, overload, and short-circuit protection, ensuring safe and stable operation.
Typical Application Scenarios
The ABB 2GUS031803A9 is widely used in various industrial sectors, including:
-
Manufacturing Plants: For controlling production lines, robotic arms, and packaging machinery.
-
Power Plants: For monitoring and controlling power generation processes.
-
Water Treatment Facilities: For managing pumps and valves in water treatment systems.
-
Oil & Gas Industry: For high-precision control and monitoring of industrial processes.
2GUS031803A9
Related Model Recommendations
-
ABB 2GUS031803A9 HESG324013R100: A variant with additional features and improved performance.
-
ABB 2GUS031803A9 HESG324013R0100: Another variant with different specifications, suitable for specific applications.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the module for physical damage, monitor output voltages using a multimeter, and check for abnormal heat generation or noises. Clean the module’s surface periodically to prevent dust accumulation, which can affect heat dissipation.
Service and Guarantee Commitment
The ABB 2GUS031803A9 comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
