ABB 100472-012

High-Resolution Touchscreen

The ABB 100472-012 features a high-resolution touchscreen, ensuring clear visibility and efficient interaction for operators。

Versatile Communication Capabilities

The panel supports multiple communication interfaces, including RS-485 Modbus RTU, allowing for seamless integration with various control systems。

Durable and Reliable Design

The ABB 100472-012 is designed with an IP65 protection rating, making it suitable for harsh industrial environments. It withstands dust and water ingress, ensuring uninterrupted operation。
In Stock
Manufacturer:
Part number: 100472-012
Our extensive catalogue, including : 100472-012 , is available now for dispatch to the worldwide. Brand:

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model ABB 100472-012
Manufacturer ABB
Product Category Operator Control Panel
Operating Voltage AC 230V / DC 24V
Dimensions (WxHxD) 100mm x 150mm x 40mm
Input/Output Ports 8 x Digital Inputs, 2 x Analog Inputs, 4 x Digital Outputs
Display 2 Line LCD Display
Communication Interface RS-485 Modbus RTU
Operating Temperature -10°C to +50°C
Storage Temperature -20°C to +70°C
Certifications UL, CE, ISO 9001
Protection Class IP65
ABB 100472-012

ABB 100472-012

Product Introduction

The ABB 100472-012 is a high-performance operator control panel designed for industrial automation systems. It offers a robust and user-friendly interface for monitoring and controlling industrial processes。

Core Advantages and Technical Highlights

High-Resolution Touchscreen

The ABB 100472-012 features a high-resolution touchscreen, ensuring clear visibility and efficient interaction for operators。

Versatile Communication Capabilities

The panel supports multiple communication interfaces, including RS-485 Modbus RTU, allowing for seamless integration with various control systems。

Durable and Reliable Design

The ABB 100472-012 is designed with an IP65 protection rating, making it suitable for harsh industrial environments. It withstands dust and water ingress, ensuring uninterrupted operation。

ABB 100472-012

ABB 100472-012

Typical Application Scenarios

The ABB 100472-012 is widely used in:
  • Manufacturing: For controlling production lines and machinery.
  • Power Generation: For monitoring and controlling critical processes in power plants.
  • Process Control: For precise control of pumps, valves, and mixers in chemical and petroleum industries.
  • Water Treatment: For managing water treatment processes and monitoring equipment.

Related Model Recommendations

  • ABB 07AI91: An analog input module suitable for applications requiring precise analog signal processing.
  • ABB PM581: A PLC module suitable for small systems.
  • ABB PM866K01: A PLC module suitable for large-scale automation.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation

Ensure the environment meets the specified temperature and humidity requirements. Use appropriate tools and safety equipment to secure the panel in place. Connect the panel to the control system according to the manufacturer’s guidelines。

Maintenance Suggestions

Regularly inspect the panel for signs of wear or damage. Keep the unit clean and free from dust to prevent overheating and ensure efficient operation。
