ABB 07CR41 1SBP260020R1001

Description

Detailed parameter table

ABB 07CR41 1SBP260020R1001

Product introduction

The ABB 07CR41 1SBP260020R1001 is a compact and reliable control relay module designed for switching and interlocking applications in industrial automation systems. As part of ABB’s low-voltage control portfolio, ABB 07CR41 1SBP260020R1001 serves as a critical interface between controllers (such as PLCs) and field devices, enabling precise control of motors, valves, lighting, and other equipment.

ABB 07CR41 1SBP260020R1001 features 8 changeover contacts, offering flexibility in configuring normally open (NO) or normally closed (NC) switching operations. Its 24 V DC operating voltage makes it compatible with standard industrial control systems, while its robust construction ensures reliable performance in harsh environments. Whether used in manufacturing lines, process plants, or building automation, ABB 07CR41 1SBP260020R1001 provides consistent switching capabilities, enhancing system efficiency and safety.

Core advantages and technical highlights

Flexible contact configuration: Each of the 8 contacts in ABB 07CR41 1SBP260020R1001 can be configured as either NO or NC, allowing customization for specific control logic requirements. In a packaging machine, this flexibility enables the module to switch conveyor motors (using NO contacts) and trigger emergency stops (using NC contacts) with a single device, reducing the number of modules needed and simplifying wiring.

Fast response times: With an operate time of <10 ms and release time of <5 ms, ABB 07CR41 1SBP260020R1001 ensures rapid switching, critical for time-sensitive applications. In a high-speed sorting system, this speed allows the module to actuate diverters within milliseconds of a sensor signal, ensuring accurate product routing and maximizing throughput.

Wide temperature tolerance: ABB 07CR41 1SBP260020R1001 operates reliably across a temperature range of -25°C to 70°C, making it suitable for both cold storage facilities and hot industrial environments like foundries. Its ability to withstand extreme temperatures without performance degradation reduces the need for environmental controls, lowering installation costs.

Typical application scenarios

In an automotive assembly line, ABB 07CR41 1SBP260020R1001 is integrated into the control system of a robotic welding station. It receives signals from the PLC to activate welding guns (via NO contacts) and deactivate conveyor belts during welding cycles (via NC contacts). The module’s fast response ensures precise timing between conveyor stops and weld initiation, preventing defects in welded components. Its compact size allows installation in the tight space of the robot control cabinet.

In a water treatment plant, ABB 07CR41 1SBP260020R1001 controls the operation of filtration system valves. It switches NO contacts to open/close solenoid valves based on pressure sensor inputs, while NC contacts monitor valve position feedback to the SCADA system. The module’s reliability in humid environments ensures consistent operation, critical for maintaining water treatment schedules and meeting regulatory standards.

ABB 07CR41 1SBP260020R1001

Related model recommendations

ABB 07CR42 1SBP260021R1001: A 16-contact variant of ABB 07CR41 1SBP260020R1001 for larger control systems requiring more switching points.

ABB 07AC11: An analog input module that, when paired with ABB 07CR41 1SBP260020R1001, enables control based on continuous process variables.

ABB PPE091A101 3BHE044481R0101: A stable 24 V DC power supply ensuring reliable operation of ABB 07CR41 1SBP260020R1001.

ABB DAPI100 3AST000929R109: A digital input module that sends signals to ABB 07CR41 1SBP260020R1001 for switching operations.

ABB CI858-1 3BSE018137R1: A communication module that allows ABB 07CR41 1SBP260020R1001 to be integrated into Ethernet-based control networks.

ABB TB857: A terminal block that provides surge protection for ABB 07CR41 1SBP260020R1001 in noisy industrial environments.

Installation, commissioning and maintenance instructions

Installation preparation: Mount ABB 07CR41 1SBP260020R1001 on a 35 mm DIN rail, ensuring at least 10mm clearance from adjacent devices for cooling. Connect 24 V DC power using 0.5mm² shielded cable, protected by a 0.5A fuse. Wire control signals to the input terminals and load devices to the output contacts using 1mm² cable, ensuring correct polarity for DC loads. Use a torque screwdriver set to 0.8 Nm for terminal connections. Power off the system during installation to prevent electrical hazards.

Maintenance suggestions: Inspect ABB 07CR41 1SBP260020R1001 semi-annually for loose connections, dust accumulation, and signs of contact wear (e.g., discoloration). Clean the module with a dry cloth or compressed air (low pressure). Test contact operation annually using a multimeter to verify continuity in both NO and NC positions. Replace the module if contacts fail to switch properly or if the coil becomes unresponsive to control signals—use only ABB-certified replacements to maintain performance.

Service and guarantee commitment

ABB 07CR41 1SBP260020R1001 is backed by a 5-year warranty from installation, covering manufacturing defects and ensuring compliance with published performance standards. ABB’s technical support team provides response within 8 hours for standard inquiries, with remote troubleshooting available during business hours. On-site service is available within 5 business days in major regions for complex issues.

The warranty includes access to technical documentation and installation guides. Extended service contracts offer annual inspections and priority support, ensuring the module maintains reliable operation throughout its 15-year design lifespan. ABB’s commitment to quality underscores confidence in ABB 07CR41 1SBP260020R1001 as a durable solution for industrial control applications.
