Description
Product Overview
The GE VMIVME-7807RC is a high – performance single – board computer (SBC) developed by GE Fanuc Embedded Systems, a subsidiary of General Electric. This board is designed for VMEbus applications and is particularly well – suited for I/O – intensive tasks in industrial automation and embedded systems.
VMIVME-7807RC integrates the Intel Pentium M processor, which comes in options of 1.1 GHz, 1.6 GHz, or 1.8 GHz. The enhanced 1.1 GHz and 1.6 GHz Pentium M processors feature 1M byte of secondary cache, while the 1.8 GHz version has 2M bytes of secondary cache. This not only provides substantial processing power but also offers excellent thermal characteristics suitable for embedded systems operating across a wide temperature range. With support for up to 1.5 GB of DDR SDRAM (with optional ECC support), the board can handle large amounts of data efficiently, making it ideal for applications that require high – speed data processing and storage. It also has a PCI – X slot and a 66 MHz PMC expansion slot, enabling easy system expansion and customization.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | VMIVME – 7807RC |
| Manufacturer | General Electric |
| Product Type | Single – Board Computer |
| Processor | Intel Pentium M (1.1 GHz / 1.6 GHz / 1.8 GHz) |
| Memory | Up to 1.5 GB DDR SDRAM (optional ECC) |
| Expansion Slots | 1 PCI – X slot, 1 66 MHz PMC expansion slot |
| Ethernet Controller | Dual gigabit Ethernet (Intel 82546EB), 10/100 Mbyte LAN (Intel 82551ER) |
| Serial Ports | Four asynchronous 16550 – compatible serial ports |
| USB Ports | Four USB 2.0 ports (two on front panel, two on rear I/O) |
| Storage | Optional up to 1 GB bootable CompactFlash on auxiliary IDE |
| Operating Systems | Windows XP, Windows 2000, VxWorks, QNX, LynxOS, Linux |
| Dimensions | 20326065MM (approximate, based on related product info) |
| Weight | 0.25 kg (approximate, based on related product info) |
| Operating Temperature Range | – 40 °C to + 85 °C |
| Power Supply | 18.5 to 36Vdc (approximate, based on related product info) |
VMIVME-7807RC
Main Features and Advantages
High – Performance Processing
The VMIVME-7807RC‘s Intel Pentium M processor, with its various speed options and significant cache sizes, can execute complex algorithms and handle multitasking with ease. This high – performance processing core enables it to meet the demands of applications that require real – time data analysis and control, such as in industrial production lines where quick decision – making based on sensor data is crucial.
Abundant Memory and Storage
With support for up to 1.5 GB of DDR SDRAM, the board can store and access large volumes of data rapidly. The optional up to 1 GB bootable CompactFlash on the auxiliary IDE provides a reliable and flexible storage solution. This is beneficial for applications that need to store programs, configuration data, and historical operation records, ensuring seamless operation even in the face of power outages or system restarts.
Versatile Connectivity
Featuring dual gigabit Ethernet ports, a 10/100 Mbyte LAN port, four asynchronous serial ports, and four USB 2.0 ports, the VMIVME-7807RC offers extensive connectivity options. The Ethernet ports enable high – speed data transfer for network – based applications, while the serial and USB ports can be used to connect a wide range of peripheral devices, from sensors and actuators in industrial settings to external storage devices or input/output modules.
Expandability
The inclusion of a PCI – X slot and a 66 MHz PMC expansion slot allows for easy system expansion. Users can add additional functionality – specific cards, such as specialized I/O cards, high – performance graphics cards for visual monitoring applications, or communication cards for connecting to unique industrial networks, tailoring the system to their exact requirements.
Application Field
The GE VMIVME-7807RC finds extensive applications in industrial automation. In manufacturing plants, it can be used to control and monitor production lines. For example, it can manage the operation of robotic arms, conveyor belts, and automated machinery, ensuring smooth production flow by processing sensor data in real – time and sending control commands.
In the energy sector, particularly in power generation plants, VMIVME-7807RC can play a vital role. It can be used to control and monitor turbines, generators, and other power – related equipment. By analyzing parameters like voltage, frequency, and power output, it helps maintain stable power generation and grid connection.
In embedded systems for transportation, such as in intelligent traffic control systems, this board can process data from traffic sensors, cameras, and other devices. It can then calculate optimal traffic light timings, manage toll – booth operations, and control vehicle – detection systems, contributing to efficient traffic management and reduced congestion.
VMIVME-7807RC
Related Products
- VMIVME – 7807: Similar to the VMIVME – 7807RC, it is also a 6U single – slot VME SBC. However, specific differences might lie in minor hardware configurations or features. It offers high – bandwidth and processing power for I/O – intensive applications, much like the VMIVME – 7807RC.
- VME – 7454: A different VME – based product. It likely serves a more specialized function within the VME system ecosystem. While the VMIVME – 7807RC focuses on general – purpose high – performance computing and I/O handling, the VME – 7454 might be designed for specific tasks, such as dedicated data storage or a particular type of communication within a VME – based industrial setup.
- VMIC – 7325: Another CPU board. It may have different performance characteristics, like a different processor or memory configuration. The VMIVME – 7807RC offers the Intel Pentium M processor and up to 1.5 GB of DDR SDRAM, while the VMIC – 7325 could be tailored for applications with different processing and memory requirements.
- VMIC VME – 7587: A Pentium VMEbus CPU board. It may have a different form factor or set of expansion options compared to the VMIVME – 7807RC. The VMIVME – 7807RC has its specific PCI – X and PMC expansion slots, and the VMIC VME – 7587 could offer alternative ways to expand the system based on different application needs.
- VMIC 5661 VMI PCI: This is a PCI – related product. It may be used in combination with the VMIVME – 7807RC to enhance PCI – related functionality. For example, while the VMIVME – 7807RC has its own PCI – X slot for expansion, the VMIC 5661 VMI PCI could be used to add more specialized PCI – based capabilities to the overall system.
Installation and Maintenance
Pre – installation preparation: Before installing the GE VMIVME-7807RC, ensure the VME chassis is compatible with the 6U board form factor. If using a PMC module, connect it to the VMIVME-7807RC prior to installation, following the PMC module’s product manual for configuration. Measure the airflow around the installation area to ensure it exceeds 450LFM, especially on the output side of the heatsink, to guarantee proper cooling.
Maintenance recommendations: Regularly check the VMIVME-7807RC for any signs of physical damage, such as cracks on the board or loose connections. Monitor the system temperature to ensure it remains within the – 40 °C to + 85 °C operating range. Periodically test the functionality of the Ethernet, serial, and USB ports to ensure seamless data transfer. If any issues arise, refer to the product’s BIOS settings (stored in battery – supported non – volatile storage) to troubleshoot, and consider restoring default settings if necessary.
Maintenance recommendations: Regularly check the VMIVME-7807RC for any signs of physical damage, such as cracks on the board or loose connections. Monitor the system temperature to ensure it remains within the – 40 °C to + 85 °C operating range. Periodically test the functionality of the Ethernet, serial, and USB ports to ensure seamless data transfer. If any issues arise, refer to the product’s BIOS settings (stored in battery – supported non – volatile storage) to troubleshoot, and consider restoring default settings if necessary.
Product Guarantee
GE stands firmly behind the quality of the VMIVME-7807RC. The company conducts rigorous quality control during the manufacturing process to ensure the board meets high – industry standards. For any manufacturing defects that occur within the warranty period, GE provides free repair or replacement services. Additionally, GE’s global network of technical support teams is available to offer assistance. Whether it’s installation guidance, troubleshooting software – related issues, or providing advice on system optimization, customers can rely on GE’s expertise. This commitment gives users confidence in the long – term performance and reliability of the VMIVME-7807RC in their industrial and embedded system applications.
