Description
Product Overview
The GE VMIVME – 5565 – 010000 332 – 015565 – 010000P is an advanced reflective memory node card designed for industrial automation and high – performance computing applications. As part of GE’s high – quality product lineup, this card is engineered to meet the stringent demands of modern industrial systems.
This card is a key component for enabling real – time data exchange within distributed systems. It features an ultra – high – speed fiber optic network, capable of data transmission at speeds up to 2.12 g baud. This makes it one of the fastest solutions in its class for applications that require rapid and deterministic data transfer. The GE VMIVME – 5565 – 010000 332 – 015565 – 010000P is designed to be independent of the operating system and bus structure. It can be easily integrated into a wide variety of setups, including those based on VMEbus, PCI, PMC, and PCI Express, ensuring seamless compatibility with existing industrial control systems. With the ability to scale up to 256 nodes, it is well – suited for large – scale distributed applications where data synchronization across multiple components is crucial.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | VMIVME – 5565 – 010000 332 – 015565 – 010000P |
| Manufacturer | GE |
| Product Type | Reflective Memory Node Card |
| Serial Connection Speed | 2.12 gbaud |
| Dynamic Packet Sizes | 4 to 64 bytes |
| On – board SRAM | Available in 128 MB or larger configurations (depending on model) |
| Form Factor | 6U VMEbus module |
| Connectors | VMEbus P1 and P2 connectors, fiber optic connector |
| Power Requirements | +5 V, +12 V, and -12 V |
| Power Consumption | 5 W |
| Operating Temperature | 0 °C to 55 °C |
| Storage Temperature | – 40 °C to 85 °C |
| Humidity | 5 % to 95 % non – condensing |
VMIVME-5565-010000 332-015565-010000P
Main Features and Advantages
High – speed data transfer: The GE VMIVME – 5565 – 010000 332 – 015565 – 010000P uses fiber optic technology to achieve ultra – fast data transfer rates. The 2.12 g baud speed ensures that data is transmitted rapidly, which is essential for real – time applications. This high – speed transfer minimizes latency, enabling quick responses in time – sensitive industrial processes.
Deterministic data delivery: It guarantees that data is delivered to all nodes within a predictable time frame. This is crucial for applications such as industrial control, where precise timing is required for the coordinated operation of multiple devices. Whether in a complex manufacturing line or a power generation system, the card ensures that data arrives on time, every time.
Versatile compatibility: Thanks to its operating system and bus structure independence, the card can be integrated into diverse industrial setups. It doesn’t matter if the existing system uses VMEbus, PCI, or other architectures; the VMIVME – 5565 – 010000 332 – 015565 – 010000P can be made to work seamlessly. This compatibility reduces the need for major system overhauls when upgrading or adding new components.
Scalability: With the capacity to support up to 256 nodes, the card is suitable for both small – scale and large – scale industrial applications. As businesses grow and their systems expand, the GE VMIVME – 5565 – 010000 332 – 015565 – 010000P can easily accommodate the increased demand for data synchronization across a larger number of devices.
Deterministic data delivery: It guarantees that data is delivered to all nodes within a predictable time frame. This is crucial for applications such as industrial control, where precise timing is required for the coordinated operation of multiple devices. Whether in a complex manufacturing line or a power generation system, the card ensures that data arrives on time, every time.
Versatile compatibility: Thanks to its operating system and bus structure independence, the card can be integrated into diverse industrial setups. It doesn’t matter if the existing system uses VMEbus, PCI, or other architectures; the VMIVME – 5565 – 010000 332 – 015565 – 010000P can be made to work seamlessly. This compatibility reduces the need for major system overhauls when upgrading or adding new components.
Scalability: With the capacity to support up to 256 nodes, the card is suitable for both small – scale and large – scale industrial applications. As businesses grow and their systems expand, the GE VMIVME – 5565 – 010000 332 – 015565 – 010000P can easily accommodate the increased demand for data synchronization across a larger number of devices.
Application Field
The GE VMIVME – 5565 – 010000 332 – 015565 – 010000P has a wide range of applications in various industries. In industrial control, it plays a vital role in ensuring the smooth operation of manufacturing processes. For example, in an automotive assembly line, it can synchronize the data between different robotic arms, conveyor belts, and quality control sensors. This synchronization allows for precise coordination, reducing errors and increasing production efficiency.
In data acquisition systems, the card is used to quickly transfer large amounts of data from multiple sensors to a central processing unit. In a power plant, numerous sensors monitor parameters such as temperature, pressure, and voltage. The VMIVME – 5565 – 010000 332 – 015565 – 010000P enables real – time data transfer from these sensors, allowing operators to monitor and control the power generation process effectively.
It is also extensively used in robotics. In a warehouse automation system with multiple autonomous robots, the card helps in sharing data related to their positions, tasks, and battery levels. This data sharing ensures that the robots can operate in a coordinated manner, avoiding collisions and optimizing their performance. Additionally, in simulation and image processing applications, the card’s high – speed and deterministic data transfer capabilities are essential for processing large amounts of data in real – time.
In data acquisition systems, the card is used to quickly transfer large amounts of data from multiple sensors to a central processing unit. In a power plant, numerous sensors monitor parameters such as temperature, pressure, and voltage. The VMIVME – 5565 – 010000 332 – 015565 – 010000P enables real – time data transfer from these sensors, allowing operators to monitor and control the power generation process effectively.
It is also extensively used in robotics. In a warehouse automation system with multiple autonomous robots, the card helps in sharing data related to their positions, tasks, and battery levels. This data sharing ensures that the robots can operate in a coordinated manner, avoiding collisions and optimizing their performance. Additionally, in simulation and image processing applications, the card’s high – speed and deterministic data transfer capabilities are essential for processing large amounts of data in real – time.
VMIVME-5565-010000 332-015565-010000P
Related Products
- GE VMIVME – 5565 – 11000 332 – 015565 – 110000P: Similar to the VMIVME – 5565 – 010000 332 – 015565 – 010000P, it is a reflective memory node card. It may have differences in memory capacity or specific performance optimizations, perhaps being more suitable for applications with higher memory requirements.
- GE VME5565: Another related product in the series. It likely shares the core functionality of high – speed data transfer and network synchronization but could have variations in form factor or interface options, making it more adaptable to different physical installation requirements.
- GE VMIC products: There are other VMIC – branded products by GE that can work in tandem with the VMIVME – 5565 – 010000 332 – 015565 – 010000P. These might include additional network cards or control modules that enhance the overall performance and functionality of the industrial system.
- GE RFM – related accessories: Accessories such as fiber optic cables specifically designed for use with GE’s reflective memory products. These cables are optimized to work with the VMIVME – 5565 – 010000 332 – 015565 – 010000P to ensure maximum data transfer speed and reliability.
- GE control system modules: Modules like those for industrial control or data processing can be integrated with the GE VMIVME – 5565 – 010000 332 – 015565 – 010000P to form a comprehensive industrial automation solution. For example, a control module can use the data transferred by the reflective memory node card to make real – time control decisions.
Installation and Maintenance
Pre – installation preparation: Before installing the GE VMIVME – 5565 – 010000 332 – 015565 – 010000P, carefully review the product manual. Ensure that the VMEbus system where it will be installed has the appropriate power supply, providing stable +5 V, +12 V, and -12 V. Check the physical dimensions of the installation location to ensure that the 6U VMEbus module can fit properly. Also, verify that the fiber optic connectors and VMEbus P1 and P2 connectors on the existing system are in good condition and compatible with the card.
Maintenance recommendations: Regularly inspect the VMIVME – 5565 – 010000 332 – 015565 – 010000P for any signs of physical damage, such as cracks on the circuit board or loose connectors. Monitor the operating temperature to ensure it remains within the 0 °C to 55 °C range. Clean the card periodically to remove dust and debris, as these can affect the performance, especially in the fiber optic connectors. Check for any firmware updates provided by GE, as these can enhance the card’s performance, add new features, or fix any known issues.
Maintenance recommendations: Regularly inspect the VMIVME – 5565 – 010000 332 – 015565 – 010000P for any signs of physical damage, such as cracks on the circuit board or loose connectors. Monitor the operating temperature to ensure it remains within the 0 °C to 55 °C range. Clean the card periodically to remove dust and debris, as these can affect the performance, especially in the fiber optic connectors. Check for any firmware updates provided by GE, as these can enhance the card’s performance, add new features, or fix any known issues.
Product Guarantee
GE stands firmly behind the quality of the GE VMIVME – 5565 – 010000 332 – 015565 – 010000P. The card undergoes strict quality control procedures during manufacturing to meet high – industry standards. GE typically offers a warranty that covers manufacturing defects for a specified period, often 12 months. In case of any quality – related issues within the warranty period, GE’s global technical support team is readily available. They can provide detailed guidance on installation, troubleshooting, and, if necessary, arrange for the repair or replacement of the VMIVME – 5565 – 010000 332 – 015565 – 010000P promptly. This reflects GE’s commitment to delivering reliable and high – performing products for industrial automation, ensuring long – term customer satisfaction.
