Description
Product Overview
The GE IS200TSVCH2AED MRP246517 is a crucial terminal board within the industrial control landscape, especially designed for seamless integration with GE’s Mark VI series systems. As part of GE’s extensive portfolio of industrial automation components, this model is engineered to meet the complex demands of modern industrial processes.
It serves as a reliable interface, facilitating the connection and transmission of various signals in industrial control setups. With its advanced design, the IS200TSVCH2AED MRP246517 enables efficient communication between different elements of the control system. This ensures that data is accurately relayed, allowing for precise control and monitoring of industrial operations. Whether in a power generation plant, manufacturing facility, or other industrial settings, this terminal board plays a pivotal role in maintaining the smooth operation of the overall automation system.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TSVCH2AED MRP246517 |
| Manufacturer | GE |
| Product Type | Terminal Board |
| Number of Channels | 24 dry contact voltage input channels |
| Input Isolation | Optical isolation up to 1500 V |
| Input Filter | Hardware filter (4 ms) |
| AC Voltage Rejection | 60 V rms at 50/60 Hz at 125 V DC excitation |
| Operating Voltage | 27.4 VDC (nominal 28.0 VDC) |
| Communication Ports | 2 Ethernet ports |
| Dimensions (approx.) | 5.1 cm x 8.3 cm x 12.7 cm |
| Weight (approx.) | 0.5 kg |
| Mounting Compatibility | Compatible with IS200TBCIH4C, IS200STCIH1A, etc. |
| Certifications | UL E207685, ATEX Zone 2 Group IIC |
IS200TSVCH2AED MRP246517
Main Features and Advantages
Robust Signal Handling
The IS200TSVCH2AED MRP246517 is equipped with 24 dry contact voltage input channels, capable of handling a diverse range of input signals. The optical isolation feature, which provides up to 1500 V of isolation, safeguards against electrical interference, ensuring the integrity of the signals. This is crucial in industrial environments where electrical noise can be a significant issue. The 4 – ms hardware input filter further enhances signal quality by removing high – frequency noise, enabling accurate data acquisition.
Versatile Compatibility
It offers remarkable compatibility with multiple terminal boards such as IS200TBCIH4C and IS200STCIH1A. This versatility allows for easy integration into different industrial control setups, whether in new installations or retrofitting existing systems. It provides users with the flexibility to choose the most suitable terminal board based on their specific requirements, streamlining the overall system design.
Clear Status Monitoring
Featuring 7 indicator lights, including 3 power indicator lights and 2 link indicator lights for Ethernet connections, the IS200TSVCH2AED MRP246517 enables users to easily monitor the status of the board. The power indicators provide quick visual confirmation of proper power supply, while the link indicators help in troubleshooting communication issues, ensuring seamless operation and efficient maintenance.
Application Field
Power Generation
In power generation plants, especially those using gas turbines, the IS200TSVCH2AED MRP246517 is deployed to connect and manage the signals related to turbine operation. It can handle inputs from sensors that monitor parameters like turbine speed, temperature, and pressure. By accurately transmitting these signals to the control system, it enables precise control of the turbine, optimizing power generation efficiency and ensuring stable power output.
Industrial Manufacturing
Industrial manufacturing facilities rely on the IS200TSVCH2AED MRP246517 to connect various sensors and actuators in their production lines. For example, in an automotive manufacturing plant, it can be used to interface with sensors that detect the position of robotic arms, conveyor belt speeds, and the presence of parts. The board’s reliable signal transmission capabilities are essential for maintaining the smooth operation of the manufacturing process, reducing downtime, and improving overall productivity.
Oil and Gas Industry
In the oil and gas sector, this terminal board plays a vital role in connecting and controlling equipment in pipelines, refineries, and drilling platforms. It can handle signals from sensors that monitor pressure, flow rates, and the status of valves. By ensuring accurate signal transfer, it helps in maintaining the safe and efficient operation of oil and gas facilities, preventing leaks and other potential hazards.
IS200TSVCH2AED MRP246517
Related Products
IS200TSVCH1A
This is a related terminal board. Compared to the IS200TSVCH2AED MRP246517, it may have different channel configurations or features. It could be more suitable for applications with lower input requirements or in less complex systems where the additional capabilities of the IS200TSVCH2AED MRP246517 are not necessary.
IS200TBCIH4C
A terminal board that is compatible with the IS200TSVCH2AED MRP246517. It provides the physical and electrical connections required for the board to interface with other components in the industrial control system. While the IS200TSVCH2AED MRP246517 focuses on signal handling, the IS200TBCIH4C complements it by enabling proper connectivity.
IS220PDIAH1A 336A4940CSP1
A discrete input module from GE. It has a different function compared to the IS200TSVCH2AED MRP246517, as it is designed for handling discrete input signals. However, in a comprehensive industrial control system, both components can work together, with the IS200TSVCH2AED MRP246517 handling voltage input channels and the IS220PDIAH1A 336A4940CSP1 managing discrete inputs.
IC698CPE010
A central processing unit (CPU) module. It is responsible for overall system control and data processing. The IS200TSVCH2AED MRP246517 feeds processed input data to the IC698CPE010, which then uses this data to execute control programs and manage the operation of the entire industrial control system.
IS215UCVEH2A
Another module that may be involved in control or communication functions within the industrial automation system. It can be integrated with the IS200TSVCH2AED MRP246517 to create a more comprehensive control solution. The IS200TSVCH2AED MRP246517 focuses on input handling, while the IS215UCVEH2A can handle other aspects of the control process, such as communication with other devices in the network.
Installation and Maintenance
Pre – installation preparation: Before installing the IS200TSVCH2AED MRP246517, ensure the power supply to the relevant part of the control system is switched off. Verify that the installation environment meets the temperature and humidity requirements specified for the board. Thoroughly review the wiring diagrams provided in the product manual. Select and securely mount the appropriate terminal board, following the compatibility guidelines. Make sure all connection points are clean and free from debris to ensure optimal electrical contact.
Maintenance recommendations: Regularly inspect the IS200TSVCH2AED MRP246517 for any signs of physical damage, such as cracks on the board or loose connections. Monitor the indicator lights to quickly identify any operational issues. Check the temperature of the board during operation to ensure it remains within the normal range. Periodically test the input channels to verify their proper functionality. If any problems are detected, refer to the detailed troubleshooting guide provided in the product documentation.
