Description
Product Overview
The GE D20 EME210BASE – T is a specialized Ethernet media converter module engineered to bridge the gap between different network media types in industrial automation and networking environments. As part of GE’s portfolio of networking solutions, this module is designed to enhance the flexibility and connectivity of industrial networks.
The GE D20 EME210BASE – T serves as a crucial link, converting Ethernet signals from a fiber – optic medium to a copper – based 10/100Base – T(X) twisted – pair medium, and vice versa. This conversion capability allows for seamless integration of various devices within an industrial network, regardless of their native connection types. In complex industrial setups where long – distance data transmission via fiber optics is required, but local connections to devices such as PLCs, HMIs, and sensors rely on copper – based Ethernet, the D20 EME210BASE – T enables smooth communication. It ensures reliable data transfer, reducing signal loss and interference, and thereby contributing to the overall stability and efficiency of the industrial automation system.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | D20 EME210BASE – T |
| Manufacturer | GE |
| Product Type | Ethernet Media Converter |
| Optical Interface | SC/PC single – mode fiber (SMF) |
| Electrical Interface | 10/100Base – T(X) RJ45 |
| Data Rate | 10 Mbps or 100 Mbps (auto – negotiation) |
| Distance (Fiber) | Up to 20 km (single – mode fiber) |
| Distance (Copper) | Up to 100 m (Category 5e or better cable) |
| Power Supply | 10 – 30 VDC |
| Power Consumption | < 3 W |
| Operating Temperature | – 40 °C to + 75 °C |
| Storage Temperature | – 40 °C to + 85 °C |
| Humidity | 5% – 95% non – condensing |
| Dimensions | 100 mm x 65 mm x 25 mm |
D20 EME210BASE-T
Main Features and Advantages
Versatile Connectivity: The GE D20 EME210BASE – T offers dual – mode connectivity with an SC/PC single – mode fiber optical interface and a 10/100Base – T(X) electrical interface. This allows it to connect to a wide range of devices, from fiber – optic – equipped switches and routers to standard copper – connected industrial controllers. Its auto – negotiation feature for data rates ensures compatibility with existing network components without the need for manual configuration in most cases.
Long – Distance Transmission: With the ability to support fiber – optic transmission distances of up to 20 km, the module is ideal for industrial applications that span large areas, such as manufacturing plants with multiple buildings or outdoor industrial sites. This long – reach capability reduces the need for repeaters or additional network infrastructure over long distances, saving costs and simplifying network design.
Rugged Industrial Design: Built to withstand harsh industrial environments, the D20 EME210BASE – T has an operating temperature range from – 40 °C to + 75 °C and can handle humidity levels from 5% – 95% non – condensing. This makes it suitable for use in factories with extreme temperature variations, outdoor installations, and other challenging industrial settings where standard networking equipment may fail.
Low Power Consumption: Consuming less than 3 W of power, the module is energy – efficient. This not only reduces operational costs but also minimizes heat generation, contributing to the reliability and longevity of the device. Additionally, its compact size of 100 mm x 65 mm x 25 mm allows for easy installation in tight spaces within industrial control cabinets.
Long – Distance Transmission: With the ability to support fiber – optic transmission distances of up to 20 km, the module is ideal for industrial applications that span large areas, such as manufacturing plants with multiple buildings or outdoor industrial sites. This long – reach capability reduces the need for repeaters or additional network infrastructure over long distances, saving costs and simplifying network design.
Rugged Industrial Design: Built to withstand harsh industrial environments, the D20 EME210BASE – T has an operating temperature range from – 40 °C to + 75 °C and can handle humidity levels from 5% – 95% non – condensing. This makes it suitable for use in factories with extreme temperature variations, outdoor installations, and other challenging industrial settings where standard networking equipment may fail.
Low Power Consumption: Consuming less than 3 W of power, the module is energy – efficient. This not only reduces operational costs but also minimizes heat generation, contributing to the reliability and longevity of the device. Additionally, its compact size of 100 mm x 65 mm x 25 mm allows for easy installation in tight spaces within industrial control cabinets.
Application Field
Manufacturing Industry: In large – scale manufacturing plants, the GE D20 EME210BASE – T is used to connect different sections of the production line. For example, it can link a central control room equipped with fiber – optic – connected servers and high – speed switches to remote areas of the plant where PLCs and sensors are connected via copper Ethernet. This enables seamless communication between the control system and the field devices, ensuring efficient production monitoring and control.
Power Generation: In power plants, the module plays a crucial role in networking various control and monitoring systems. It can connect fiber – optic – based communication links from remote monitoring stations to the main control center, while also interfacing with copper – connected local devices such as turbine control units and power distribution monitoring equipment. This ensures reliable data transfer for power generation optimization and safety management.
Oil and Gas Industry: In oil refineries and gas processing plants, which often cover large geographical areas, the D20 EME210BASE – T is used to establish stable network connections. It can connect fiber – optic networks laid across the plant site to copper – connected field instruments, control panels, and safety systems. This helps in real – time monitoring of critical processes, ensuring operational safety and efficient production.
Power Generation: In power plants, the module plays a crucial role in networking various control and monitoring systems. It can connect fiber – optic – based communication links from remote monitoring stations to the main control center, while also interfacing with copper – connected local devices such as turbine control units and power distribution monitoring equipment. This ensures reliable data transfer for power generation optimization and safety management.
Oil and Gas Industry: In oil refineries and gas processing plants, which often cover large geographical areas, the D20 EME210BASE – T is used to establish stable network connections. It can connect fiber – optic networks laid across the plant site to copper – connected field instruments, control panels, and safety systems. This helps in real – time monitoring of critical processes, ensuring operational safety and efficient production.
D20 EME210BASE-T
Related Products
- GE D20 EME210BASE – SX: Similar to the D20 EME210BASE – T, but it uses multimode fiber (MMF) instead of single – mode fiber. It is suitable for shorter – distance applications, typically up to 550 m, and is often used in smaller industrial facilities or indoor environments where the fiber – optic link lengths are not as long.
- GE D20 EME220BASE – T: An upgraded version with potentially enhanced features such as higher data rate support, more advanced management capabilities, or improved power efficiency. It may offer additional functionality for more complex industrial networking requirements.
- GE D20 EME200 – 2S: A dual – fiber media converter that has two fiber – optic interfaces. It can be used in scenarios where redundant fiber – optic connections are required for increased network reliability, such as in mission – critical industrial applications.
- Hirschmann MACH10 – 2TX2FX: A competing product from Hirschmann. It also provides Ethernet media conversion functionality but may have different interface types, performance characteristics, or management features. Comparing it with the GE D20 EME210BASE – T can help users choose the most suitable option for their specific industrial networking needs.
- Moxa IMC – 101 – S – ST: Another media converter from Moxa. It offers different fiber – optic connector types and may have unique software features for network configuration and monitoring. It can be considered as an alternative for industrial Ethernet media conversion tasks.
Installation and Maintenance
Pre – installation preparation: Before installing the GE D20 EME210BASE – T, ensure that the power supply voltage within the installation area is within the 10 – 30 VDC range specified for the module. Check the integrity of the fiber – optic cables and copper Ethernet cables that will be connected to the module, ensuring there are no cuts, kinks, or damaged connectors. Verify that the installation location meets the environmental requirements, including temperature and humidity conditions. When mounting the module, use the provided mounting brackets or DIN – rail mount to securely attach it to the control cabinet or equipment rack.
Maintenance recommendations: Regularly inspect the D20 EME210BASE – T for any signs of physical damage, such as cracked enclosures or loose connectors. Monitor the power supply voltage to ensure it remains within the specified range. Periodically check the status indicators on the module to verify its normal operation; for example, check that the link and activity lights for both the fiber – optic and copper interfaces are functioning correctly. Clean the fiber – optic connectors gently using a lint – free cloth and appropriate cleaning solution to maintain optimal signal transmission. In case of any network connectivity issues, refer to the product manual for troubleshooting steps, and if necessary, contact GE’s technical support for assistance.
Product Guarantee
GE stands firmly behind the quality of the GE D20 EME210BASE – T. The module undergoes strict quality control procedures during manufacturing to meet high – industry standards. In case of any manufacturing defects, GE offers a comprehensive warranty. Their global network of technical support teams is available to assist customers promptly. Whether it’s providing guidance on installation, helping with complex troubleshooting, or offering advice on maintenance, GE’s experts are dedicated to ensuring the long – term reliable operation of the D20 EME210BASE – T. This reflects GE’s commitment to delivering top – notch products and excellent customer service, instilling confidence in users that the module will perform reliably in their industrial networking applications.
