ABB 3BHB009175R0001

Description

ABB 3BHB009175R0001 Product Overview

Technical Specifications

Parameter Name	Parameter Value
Product Model	3BHB009175R0001
Manufacturer	ABB
Product Type	Industrial Power Supply Module
Input Voltage	100–240 V AC (wide-range input)
Output Voltage	24 V DC ±1%
Output Current	10 A continuous
Power Rating	240 W
Efficiency	Up to 90% at full load
Isolation	Input-to-output isolation (2.5 kV AC)
Operating Temperature	-20°C to +60°C (with derating above +50°C)
Dimensions (W×H×D)	100 mm × 160 mm × 125 mm
Mounting Method	DIN rail or panel mounting
Certification	CE, UL, IEC 61000-4-2/3/4, RoHS
Redundancy Support	Yes (parallel operation with identical modules)

O3EId HENF452777R3

Key Features and Advantages

1. Stable Power Delivery:
   • Provides regulated 24 V DC output with low ripple noise (<1% of rated voltage), ensuring reliable power for sensitive automation components like PLCs and sensors.
   • Features active PFC (power factor correction) to minimize harmonic distortion and improve energy efficiency in AC input systems.
2. Robust Design for Harsh Environments:
   • Conformal-coated circuitry protects against dust, moisture, and corrosive gases, making it suitable for industrial environments with high humidity or airborne contaminants.
   • Built-in overvoltage, overcurrent, and short-circuit protection safeguards connected devices and prevents cascading failures.
3. Redundancy and Scalability:
   • Supports parallel operation with identical modules (e.g., 3BHB009175R0002) to create redundant power systems, eliminating single points of failure in critical applications like oil refineries or pharmaceutical production lines.
   • Modular design allows easy replacement without powering down the entire system (hot-swappable in compatible enclosures).
4. Easy Integration and Monitoring:
   • LED indicators for power status (green) and fault conditions (red), enabling quick visual diagnostics.
   • Compatible with ABB’s System 800xA and other third-party SCADA systems via optional communication modules (e.g., Modbus RTU interface for remote monitoring of voltage/current levels).

Application Scenarios

• Manufacturing: Powers PLCs, HMIs, and robotic controllers in automotive assembly lines, ensuring consistent operation during high-volume production.
• Energy and Utilities: Used in power plants to supply stable power to turbine control systems, SCADA networks, and emergency shutdown (ESD) systems.
• Process Industries: Supports control modules in chemical plants, water treatment facilities, and food processing lines, where uninterrupted power is critical for safety and compliance.
• Marine and Offshore: Deployed in ship automation systems and offshore platforms, thanks to its rugged design and compliance with marine certification standards (e.g., DNV GL upon request).


  CI546 3BSE012545R1

Related Products

• ABB 3BHB009176R0001: A higher-current variant (15 A output) for systems with heavier power demands.
• ABB PM866AK01 (AC 800M Controller): A compatible controller that pairs with the 3BHB009175R0001 in ABB’s DCS solutions.
• ABB TB521 Terminal Block: Provides secure wiring for power input/output connections.
• ABB UNITROL 6800: A voltage regulator for generator control systems, often used alongside the 3BHB009175R0001 in power generation applications.
• ABB Redundancy Module (e.g., 3BHB002830R0101): Enables seamless failover between redundant power supplies in critical systems.

Installation and Maintenance

• Installation:
  1. Mount the module on a DIN rail or panel in a control cabinet, ensuring at least 25 mm of clearance for airflow.
  2. Connect the AC input (L/N/GND) using stranded or solid copper wires (recommended AWG 14–22).
  3. Connect the 24 V DC output to the load or distribution terminal block, ensuring proper polarity.
  4. For redundancy, install a second 3BHB009175R0001 in parallel using ABB’s redundancy kit (sold separately).
• Maintenance:
  • Regularly inspect LED indicators for fault signals and clean dust from vents using compressed air (every 6–12 months).
  • Test input/output voltages with a multimeter annually to ensure compliance with specifications.
  • Replace the module if unusual noise, overheating, or voltage fluctuations occur, as these may indicate internal component wear.
