1. Product Description
The ABB 5SHY35L4503 is a high-performance IGBT (Insulated Gate Bipolar Transistor) module designed for demanding power conversion applications. As a key component in ABB’s semiconductor portfolio, the 5SHY35L4503 combines advanced switching capabilities with robust thermal management, making it ideal for use in inverters, converters, and motor drives across industries. Paired with accessories 3BHB004693R0001 (gate driver board) and 3BHB004692R0002 (baseplate cooler), this solution forms a complete power module system. Additionally, the 5SXE01-0127 is a silicon carbide (SiC) MOSFET module from ABB, offering ultra-low switching losses and high-frequency operation for next-generation energy systems. Together, these products highlight ABB’s expertise in delivering reliable, efficient power electronics.
2. Product Parameters
5SHY35L4503 (IGBT Module)
| Parameter | Details |
|---|---|
| Voltage Rating | 4500 V |
| Current Rating (Tc=125°C) | 1800 A |
| Configuration | Half-bridge with anti-parallel diodes |
| Package Type | Press-fit technology for easy integration |
| Switching Frequency | Up to 20 kHz |
| Thermal Resistance (Rth(j-c)) | 0.015 K/W |
| Cooling Method | Liquid-cooled (compatible with 3BHB004692R0002 cooler) |
3BHB004693R0001 (Gate Driver Board)
| Parameter | Details |
|---|---|
| Supply Voltage | 20–30 VDC |
| Output Current | ±15 A (peak) |
| Isolation | 3000 Vrms galvanic isolation |
| Control Interface | Optocoupler-based signal input |
| Protection Features | Overvoltage, overcurrent, and temperature monitoring |
3BHB004692R0002 (Baseplate Cooler)
| Parameter | Details |
|---|---|
| Material | Copper baseplate with aluminum fins |
| Cooling Media | Water/glycol mixture |
| Pressure Rating | 10 bar |
| Dimensions | Customizable for module integration |
5SXE01-0127 (SiC MOSFET Module)
| Parameter | Details |
|---|---|
| Voltage Rating | 1200 V |
| Current Rating (Tc=25°C) | 180 A |
| Rds(on) | 17 mΩ |
| Switching Frequency | Up to 1 MHz |
| Package Type | Press-fit with isolated baseplate |
5SHY35L4503 3BHB004693R0001 3BHB004692R0002 5SXE01-0127
3. Advantages and Features
- High Efficiency: The 5SHY35L4503 IGBT module achieves low conduction losses (<1.5 V at rated current) and fast switching speeds, improving system efficiency by up to 15% compared to older-generation IGBTs. The 5SXE01-0127 SiC MOSFET reduces switching losses by 70%, enabling higher frequency operation and smaller passive components.
- Rugged Design: The press-fit package of both modules eliminates wire bonds, enhancing reliability in high-vibration environments. The 3BHB004692R0002 cooler ensures thermal stability, with a heat dissipation capacity of up to 50 kW.
- Integrated Protection: The 3BHB004693R0001 driver board includes active clamping and desaturation detection, protecting the IGBT from overvoltage and short-circuit faults.
- Scalability: ABB’s modular design allows easy parallel operation for higher power requirements, supporting systems from 100 kW to multi-MW applications.
4. Application Fields and Application Cases
Industry Applications:
- Renewable Energy: Wind turbine converters (5SHY35L4503), solar inverters (5SXE01-0127), and energy storage systems.
- Industrial Drives: High-power motor drives for pumps, compressors, and rolling mills.
- Transportation: Traction inverters for electric vehicles and rail systems.
- Grid Infrastructure: HVDC converters and flexible AC transmission systems (FACTS).
Application Case:
A leading wind turbine manufacturer integrated the 5SHY35L4503 into its 6 MW offshore wind turbine converters. The module’s high voltage rating and thermal efficiency reduced the converter size by 30% while improving energy capture by 5% through faster dynamic response. The 配套的 3BHB004693R0001 and 3BHB004692R0002 ensured reliable operation in harsh marine environments, with zero unplanned downtime over 50,000 hours of operation.
A leading wind turbine manufacturer integrated the 5SHY35L4503 into its 6 MW offshore wind turbine converters. The module’s high voltage rating and thermal efficiency reduced the converter size by 30% while improving energy capture by 5% through faster dynamic response. The 配套的 3BHB004693R0001 and 3BHB004692R0002 ensured reliable operation in harsh marine environments, with zero unplanned downtime over 50,000 hours of operation.
5. Competing Product Comparison
Compared to similar power modules, the ABB 5SHY35L4503 and 5SXE01-0127 stand out for their thermal performance and integration level. The press-fit technology reduces assembly complexity by 50% compared to soldered packages, while the SiC MOSFET’s ultra-low Rds(on) and high-frequency capability outperform traditional silicon MOSFETs in compact, high-efficiency designs. ABB’s comprehensive ecosystem of drivers and coolers also provides a more streamlined solution than fragmented third-party component sets.
5SHY35L4503 3BHB004693R0001 3BHB004692R0002 5SXE01-0127
6. Selection Suggestions
- Power Requirements: Choose the 5SHY35L4503 for high-voltage (≥1000 V), high-current applications, and the 5SXE01-0127 for medium-voltage, high-frequency needs (e.g., <1500 V, >20 kHz).
- Cooling System: Ensure the 3BHB004692R0002 cooler’s flow rate (≥5 L/min) and pressure compatibility with your system’s cooling loop.
- Control Interface: Verify the 3BHB004693R0001 driver’s signal compatibility with your controller (e.g., TTL/CMOS inputs).
- Efficiency Goals: For applications prioritizing energy savings, the SiC-based 5SXE01-0127 is ideal, while the IGBT-based 5SHY35L4503 offers a balance of cost and performance.
7. Precautions
- Installation: Use ABB-recommended torque specifications (10–12 N·m) for mechanical mounting to avoid package stress. Ensure proper alignment of the cooler and module for optimal heat transfer.
- Electrical Handling: Always ground the module during installation to prevent electrostatic discharge (ESD) damage. Use shielded cables for gate driver connections to minimize noise interference.
- Maintenance: Regularly inspect the cooling system for leaks or debris, as poor thermal management can reduce module lifespan by up to 50%. Monitor driver board diagnostics for early detection of component wear.
