The ABB 3HAB8101-19 DSQC545A stands out for its modular design, which allows flexible configuration of I/O channels to adapt to diverse application needs. Its high-speed Ethernet interface ensures real-time data exchange, critical for synchronized robotic movements in complex workflows. The module’s built-in diagnostic functions enable quick fault detection, minimizing downtime and maintenance costs. For example, its self-test feature can identify communication errors within milliseconds, ensuring continuous operation in high-demand production lines. Additionally, the module’s rugged construction meets IP20 standards, protecting against dust and minor impacts in industrial settings.
In Stock
Manufacturer: Driver Part number: 3HAB8101-19 DSQC545A
Our extensive Driver catalogue, including
: 3HAB8101-19 DSQC545A
, is available now for dispatch to the worldwide.
Brand: ABB
ABB 3HAB8101-19 DSQC545A is a high-performance robotic interface module designed to enhance the connectivity and control capabilities of industrial robotic systems. As a key component in ABB’s robotics portfolio, the 3HAB8101-19 DSQC545A serves as a vital link between robotic controllers and peripheral devices, enabling seamless data transmission and precise motion coordination. This module is engineered to withstand harsh industrial environments, making it suitable for applications requiring reliability and durability. The ABB 3HAB8101-19 DSQC545A is renowned for its intuitive integration with ABB’s robot controllers, reducing setup time and improving overall system efficiency.
2. Product Parameters
Parameter
Details
Model Number
3HAB8101-19 DSQC545A
Manufacturer
ABB
Type
Robotic Interface Module
Voltage Supply
24 V DC ±10%
Current Consumption
Typically 0.5 A (depending on connected devices)
Communication Interfaces
Ethernet, Digital I/O (24 inputs / 16 outputs), Analog I/O (4 channels)
Compatibility
ABB IRC5 robot controllers and various robotic models (e.g., IRB series)
Operating Temperature
0°C to 50°C
Dimensions
Approx. 200 mm (W) x 150 mm (H) x 100 mm (D)
Weight
1.2 kg
3HAB8101-19 DSQC545A
3. Advantages and Features
The ABB 3HAB8101-19 DSQC545A stands out for its modular design, which allows flexible configuration of I/O channels to adapt to diverse application needs. Its high-speed Ethernet interface ensures real-time data exchange, critical for synchronized robotic movements in complex workflows. The module’s built-in diagnostic functions enable quick fault detection, minimizing downtime and maintenance costs. For example, its self-test feature can identify communication errors within milliseconds, ensuring continuous operation in high-demand production lines. Additionally, the module’s rugged construction meets IP20 standards, protecting against dust and minor impacts in industrial settings.
4. Application Areas and Case Studies
This module is widely used in manufacturing industries, particularly in automotive assembly, electronics production, and material handling. It excels in scenarios requiring precise control over robotic arms, such as pick-and-place operations, quality inspection, and welding.
Case Study: A leading automotive manufacturer integrated the 3HAB8101-19 DSQC545A into its robotic welding line. The module’s high-speed data processing capabilities reduced cycle time by 15%, while its reliable I/O interface minimized errors in tool changover sequences. This resulted in a 20% improvement in overall production efficiency and a significant reduction in defect rates.
5. Competitor Comparison
Compared to similar interface modules on the market, the ABB 3HAB8101-19 DSQC545A offers superior software compatibility with ABB’s ecosystem, including RobotStudio programming tools and safety systems. Its pre-configured protocols for common industrial fieldbuses (e.g., PROFINET, DeviceNet) eliminate the need for custom programming, saving time during integration. The module’s robust thermal design also ensures stable performance in high-temperature environments, outperforming alternatives with lower heat tolerance.
3HAB8101-19 DSQC545A
6. Selection Recommendations
When selecting the 3HAB8101-19 DSQC545A, consider the following:
Compatibility: Ensure it aligns with your existing ABB robot model and controller version.
I/O Requirements: Assess the number of digital/analog channels needed for your application.
Environmental Conditions: Verify that the module’s temperature and protection ratings suit your facility.
Scalability: Plan for future expansions by choosing a module with extra configurable channels.
7. Precautions
Installation: Follow ABB’s guidelines to ensure proper grounding and cable routing, avoiding electromagnetic interference.
Power Supply: Use a regulated 24 V DC power source to prevent voltage fluctuations that may damage the module.
Maintenance: Regularly inspect connectors for dust or corrosion, and update firmware periodically to benefit from performance improvements.
Safety: Disconnect power before performing any maintenance or hardware changes to avoid electric shock.
