The GE MMII – PD – 1 – 2 – 120 is a highly advanced Motor Manager II device by General Electric, designed to be a cornerstone in motor protection and control within industrial automation systems. It belongs to GE’s renowned Multilin product series, which are globally recognized for their reliability and performance. This device is specifically engineered to monitor, protect, and control motors in various industrial applications.
The GE MMII – PD – 1 – 2 – 120 comes equipped with a built – in display, which provides real – time information about the motor’s operational status. It can detect and safeguard against a wide range of motor issues, such as overloads, short circuits, and phase imbalances. By accurately measuring parameters like current, voltage, and power, it ensures the efficient and safe operation of motors. This not only extends the lifespan of motors but also minimizes unplanned downtime, thereby enhancing overall productivity in industrial settings. Its integration capabilities make it a seamless addition to existing control systems, providing users with enhanced control and monitoring capabilities.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MMII – PD – 1 – 2 – 120 |
| Manufacturer | GE |
| Product Type | Motor Protection and Control Device |
| Input Voltage Range | Suitable for common industrial voltage levels |
| Current Sensing Range | Wide range to accommodate different motor sizes |
| Display Type | Built – in display for status monitoring |
| Communication Protocols | Supports industry – standard protocols for easy integration |
| Protection Functions | Overload, short circuit, phase imbalance protection |
| Mounting Type | Standard industrial mounting options available |
| Operating Temperature | -20°C to 60°C |
| Humidity Range | 5% – 95% non – condensing |
