Description
Product Overview
The GE IS215UCVEH2AF is a pivotal VME controller board within the renowned Mark VI series, designed by General Electric. This board plays a crucial role in the management and control of industrial gas and steam turbine systems, which are fundamental in various industrial applications.
Functioning as the nerve center of the control system, the IS215UCVEH2AF is equipped with a high – speed processor. This enables it to execute complex control algorithms with great precision and speed, ensuring the smooth operation of turbines. It features an array of components such as DRAM, cache, and flash memory, which are essential for data storage and quick access during the control process. With interfaces like two serial RS – 232C ports and an Ethernet port, it can easily communicate with other devices within the system. This seamless communication allows for real – time data transfer and control, making it an integral part of the overall automation infrastructure.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS215UCVEH2AF |
| Manufacturer | GE |
| Product Type | VME Controller Board |
| Series | Mark VI |
| Microprocessor | Intel Celeron 300 MHz |
| Memory | 32 MB DRAM, with flash memory (amount not specified in source but other models in series have 16 or 128 MB) |
| Ethernet Interface | 10BaseT/100BaseTX, RJ – 45 connector (primary) |
| COM Ports | COM1 |
| Power Requirements | +5 V DC, 6 A typical, 8 A max |
| Operating System | QNX |
| Operating Temperature | -30 to 65 °C |
| Size | 8.26 cm high x 4.19 cm |
| Weight | 2 lbs |
| Programming | Boolean |
IS215UCVEH2AF
Main Features and Advantages
High – Performance Processing
The IS215UCVEH2AF is powered by an Intel Celeron 300 MHz processor. This high – speed processing unit allows the board to handle complex control tasks efficiently. In industrial turbine control, it can quickly analyze sensor data, make real – time decisions, and adjust control parameters. For example, it can rapidly respond to changes in turbine speed or temperature, ensuring stable and optimal operation.
Reliable Memory Configuration
With 32 MB of DRAM and flash memory (capacities may vary as per different models in the series), the board offers reliable data storage. The DRAM enables fast access to data during operation, while the flash memory ensures that critical system data and configurations are retained even during power outages. This reliability is crucial for maintaining continuous and accurate control in industrial settings.
Versatile Communication Interfaces
Featuring an Ethernet port (10BaseT/100BaseTX with RJ – 45 connector) and a COM1 port, the IS215UCVEH2AF can establish seamless communication with a wide range of devices. The Ethernet port allows for high – speed data transfer, which is essential for communicating with other control systems, monitoring stations, or for remote access and control. The COM1 port can be used for connecting to serial devices, providing flexibility in system integration.
Application Field
Power Generation Plants
In power generation plants that utilize gas or steam turbines, the IS215UCVEH2AF is at the heart of the control system. It monitors and controls various aspects of turbine operation, such as fuel supply, speed regulation, and temperature control. By ensuring the turbines operate at peak efficiency, it contributes to stable and reliable power generation, meeting the electricity demands of industries and consumers.
Industrial Manufacturing Facilities
Industrial manufacturing plants often rely on turbines for powering large – scale machinery. The IS215UCVEH2AF is used to manage these turbines, ensuring smooth operation of the manufacturing processes. For instance, in a steel mill, it controls the turbines that power the heavy – duty rolling mills, helping to maintain consistent production quality and efficiency.
Oil and Gas Industry
In the oil and gas sector, turbines are used for various purposes, including powering compressors in pipelines and driving pumps in refineries. The IS215UCVEH2AF plays a vital role in controlling these turbines. It monitors parameters like pressure, flow rates, and equipment status, and adjusts turbine operation accordingly. This helps in optimizing the production and transportation processes, reducing downtime, and enhancing overall productivity in the oil and gas industry.
IS215UCVEH2AF
Related Products
IS215UCVEM01A
This is a related controller module. It has additional features compared to the IS215UCVEH2AF, such as support for additional Ethernet ports and Profibus. It is suitable for applications that require more extensive network connectivity options and the ability to interface with Profibus – compatible devices.
IS215UCVFH2A
Another card in the series, likely with different processing capabilities or interface configurations. It may be designed for specific applications where the requirements for processing power or communication interfaces differ from those met by the IS215UCVEH2AF.
IS200TBCIH4C
A terminal board that can be used in conjunction with the IS215UCVEH2AF. It provides the necessary physical and electrical connections for the controller board to interface with other components in the industrial control system, facilitating signal transfer and power supply.
IS220PDIAH1A 336A4940CSP1
A discrete input module. While the IS215UCVEH2AF focuses on overall control and processing, this module is responsible for handling discrete input signals. In a comprehensive industrial control system, they work together, with the discrete input module feeding input data to the IS215UCVEH2AF for further processing and control.
IC698CPE010
A central processing unit (CPU) module from a different series. It has its own set of capabilities and applications. In some industrial control setups, it can be integrated with the IS215UCVEH2AF, where the IS215UCVEH2AF may handle turbine – specific control tasks, and the IC698CPE010 manages other aspects of the overall system control.
Installation and Maintenance
Pre – installation preparation: Before installing the IS215UCVEH2AF, make sure the power to the relevant part of the control system is switched off. Thoroughly review the installation manual provided by GE, which contains detailed instructions on proper handling and connection. Check the compatibility of the board with other components in the system, such as the VME rack it will be installed in. Ensure that the installation environment meets the temperature and humidity requirements specified for the board to prevent any potential damage.
Maintenance recommendations: Regularly inspect the IS215UCVEH2AF for any signs of physical damage, like cracks on the board or loose connections. Monitor the temperature of the board during operation to ensure it remains within the specified range. Periodically check the functionality of the communication interfaces by sending test signals. If any issues are detected, refer to the troubleshooting guide in the product manual. GE also offers software updates periodically, so it is important to keep the board’s software up – to – date to benefit from performance improvements and bug fixes.
Product Guarantee
GE stands firmly behind the quality of the IS215UCVEH2AF. The company offers a comprehensive quality assurance program. In case of any manufacturing defects, GE’s global network of technical support teams is readily available to provide prompt assistance. They can offer guidance on installation, operation, and troubleshooting. GE conducts rigorous testing during the manufacturing process to ensure the board meets the highest industry standards. This commitment to quality gives customers confidence in the long – term performance and reliability of the IS215UCVEH2AF in their industrial control applications.
