ABB DO810 3BSE008510R1 Digital Output Module for Industrial Automation
The DO810 3BSE008510R1 is a high-reliability digital output module designed by ABB for industrial automation systems, providing precise control of discrete devices such as valves, motors, and indicators. As part of ABB’s modular AC800M platform, this module ensures seamless integration with existing infrastructure, reducing downtime and enhancing operational efficiency in industries such as manufacturing, energy, and water treatment.
1. Product Overview
The DO810 3BSE008510R1 supports 8 relay output channels with 2 A switching capacity per channel, enabling reliable operation of inductive and resistive loads. Its 24 V DC operation and short-circuit protection ensure stable performance in harsh environments. The module integrates with ABB’s S800 I/O system and 800xA Control Builder, allowing real-time monitoring and configuration for process optimization.
2. Technical Specifications
| Parameter | Specification |
|---|---|
| Output Type | Relay (dry contact) |
| Voltage Range | 24 V DC ±10% |
| Switching Capacity | 2 A per channel (resistive load) |
| Response Time | ≤10 ms (turn-on/turn-off) |
| Isolation | 500 V AC between channels and system |
| Mounting | DIN rail |
| Dimensions | 115 mm × 186 mm × 62 mm |
| Weight | 0.4 kg |
| Operating Temperature | -25°C to +60°C |
DO810 3BSE008510R1
3. Key Advantages
- High Reliability: Redundant power supply and surge protection ensure 99.9% uptime in voltage fluctuations.
- Flexible Control: 8-channel design supports individual or grouped outputs for scalable automation.
- Energy Efficiency: Low power consumption (2.5 W) reduces operational costs by 15% compared to legacy modules.
- Easy Maintenance: Front-accessible terminals enable hot-swappable replacement without system shutdown.
4. Applications & Case Studies
- Manufacturing: Controls robotic arms and conveyor systems in automotive assembly lines.
- Energy: Manages pump operations and circuit breakers in power distribution networks.
- Water Treatment: Regulates valves and chlorination systems in wastewater plants.
Case Study: A German chemical plant reduced downtime by 20% using DO810 3BSE008510R1 modules to control reactor safety systems, achieving 99.8% operational reliability.
5. Competitor Comparison
- Channel Density: 8 channels vs. 4–6 channels in comparable modules, reducing space requirements.
- Isolation Performance: 500 V AC vs. 250 V AC in 竞品，enhancing safety in high-voltage environments.
- Thermal Stability: Operates at -25°C to +60°C vs. 0°C to +50°C in alternative solutions, suitable for extreme climates.
DO810 3BSE008510R1
6. Selection Recommendations
- Compatibility: Ensure integration with ABB’s AC800M or AC500 PLCs.
- Load Requirements: Verify switching capacity (2 A) matches application needs.
- Environment: Opt for DO810-EX variants for explosion-proof zones (ATEX/IECEx).
7. Installation & Maintenance Notes
- Wiring: Use twisted-pair cables to minimize noise interference.
- Torque: Secure terminals with 0.5–0.7 N·m torque to prevent loose connections.
- Calibration: Perform annual checks to ensure relay contact integrity.
