Description
Product Overview
The GE 516TX 336A4940DNP516TX is a high – performance 16 – port Ethernet network switch developed by General Electric. As part of the N – Tron 516TX series, it plays a crucial role in industrial networking. This switch is specifically designed for industrial applications, fitting seamlessly into the Mark VIe control system family. Its primary function is to enable reliable and high – speed connectivity among various Ethernet – enabled devices in industrial settings.
In industrial automation systems, the GE 516TX 336A4940DNP516TX serves as a central hub, allowing for the connection of programmable logic controllers (PLCs), supervisory control and data acquisition (SCADA) systems, and industrial computers. By facilitating efficient data transfer, it ensures smooth operation of complex industrial processes. Its modular and expandable architecture makes it adaptable to different industrial requirements, whether in a small – scale factory or a large – scale power generation plant. This switch is not only about providing basic connectivity but also about enhancing the overall performance and reliability of industrial control networks.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 516TX 336A4940DNP516TX |
| Manufacturer | General Electric |
| Product Type | Ethernet Network Switch |
| Number of Ports | 16 |
| Ethernet Standards | IEEE 802.3, IEEE 802.3u (10Base – T/100Base – TX), IEEE 802.3ab (Gigabit Ethernet) |
| Data Transfer Rate | 10/100/1000 Mbps |
| Power over Ethernet (PoE) | Optional |
| Switching Capacity | 128 Gbps |
| Frame Size | 128 – 1518 bytes |
| Protocol Compatibility | IPv4, IPv6, TCP, UDP, ARP, ICMP, SNMP |
| Operating Temperature | – 40 °C to + 75 °C |
| Housing Material | Ruggedized metal |
| Mounting Option | DIN – rail, panel, and rack (with kits) |
516TX 336A4940DNP516TX
Main Features and Advantages
Industrial – Grade Durability
The GE 516TX 336A4940DNP516TX is built with a ruggedized metal housing, enabling it to endure harsh industrial environments. With an operating temperature range from – 40 °C to + 75 °C, it can function optimally in extreme conditions, whether it’s the freezing cold of a mining site or the sweltering heat of a steel mill. Its resistance to shock and vibration makes it reliable in facilities with heavy machinery operation.
High – Speed and Reliable Connectivity
Featuring 16 ports that support 10/100/1000 Mbps data transfer rates, this switch offers high – speed data flow. The advanced IEEE 802.3 fast Ethernet 10/100Base – TX switching technology minimizes network collisions, ensuring a stable and deterministic network performance. The high – speed processor and backplane provide a remarkable throughput of up to 128 Gbps, facilitating seamless communication among connected devices.
Advanced Management Functions
It comes with a suite of advanced management features. VLAN support (802.1q) allows for network segmentation, enhancing security and performance. Quality of Service (QoS) ensures that critical data traffic is prioritized, which is essential for real – time industrial control applications. Features like port mirroring, IGMP snooping, and Rapid Spanning Tree Protocol (RSTP) support further optimize network management and reliability.
Application Field
Industrial Automation
In factory automation, the GE 516TX 336A4940DNP516TX connects various automated machinery, robots, and PLCs. It enables real – time data exchange, allowing for precise control and coordination of production processes. For example, in an automotive assembly line, it ensures that different robotic arms and conveyor belts communicate effectively, optimizing production speed and quality.
Power Generation
Power plants rely on this switch to network different components such as generators, turbines, and control systems. It enables remote monitoring and control of power generation equipment, ensuring stable power output. In a hydroelectric power plant, the switch helps in connecting sensors and actuators that manage water flow and turbine speed, contributing to efficient power generation.
Process Control
In industries like chemical and food processing, the GE 516TX 336A4940DNP516TX is used to implement network – based control systems. It connects sensors that monitor temperature, pressure, and flow rates to control valves and pumps. This ensures accurate process control, maintaining product quality and safety in these industries.
516TX 336A4940DNP516TX
Related Products
GE 517TX
A similar switch in the series, likely with additional ports or enhanced performance capabilities. It can be used in scenarios where more extensive connectivity or higher – speed data transfer is required, such as in large – scale industrial complexes with numerous devices to connect.
GE 513TX
This model may have fewer ports, making it suitable for smaller – scale industrial applications or for areas where a more compact and cost – effective networking solution is needed.
GE IC697ACC700
A communication module that can be integrated with the GE 516TX 336A4940DNP516TX to expand the communication capabilities of the overall industrial control system, enabling connection with more diverse types of devices.
GE IC698CHS100
A high – speed Ethernet communication module. When used in tandem with the GE 516TX 336A4940DNP516TX, it can further boost the data transfer speed and efficiency within the industrial network, beneficial for applications demanding rapid data exchange.
GE 336A4941DNP516TX
Possibly an upgraded version of the GE 516TX 336A4940DNP516TX, with potential improvements in features like enhanced security protocols, more advanced management functions, or better performance in challenging industrial environments.
Installation and Maintenance
Pre – installation preparation: Before installing the GE 516TX 336A4940DNP516TX, ensure the installation area is clean and free from excessive dust and moisture. Check the power supply voltage to match the switch’s requirements. Verify the physical space available, as it can be mounted on DIN – rails, panels, or racks with appropriate kits. Plan the network layout, determining which devices will be connected to each port. Make sure all the connecting cables are in good condition and of the correct type for Ethernet connections.
Maintenance recommendations: Regularly clean the GE 516TX 336A4940DNP516TX to prevent dust accumulation, which could affect performance. Monitor the status LEDs on the switch to check for any connection or operational issues. Periodically update the switch’s firmware to benefit from the latest features and security enhancements. If any port shows signs of malfunction, check the cable connections first and then, if necessary, consult the product manual for further troubleshooting steps.
Product Guarantee
General Electric stands firmly behind the GE 516TX 336A4940DNP516TX. The product undergoes strict quality control during manufacturing to meet high – industry standards. GE offers a standard warranty period, during which any manufacturing defects will be rectified through repair or replacement services free of charge. Their global network of technical support teams is available to assist customers with installation guidance, configuration advice, and troubleshooting. This commitment reflects GE’s confidence in the product’s quality and its dedication to providing reliable industrial networking solutions, ensuring customers’ peace of mind when integrating the GE 516TX 336A4940DNP516TX into their critical industrial operations.
