Product Core Brief
- Model:
- Brand: FOXBORO
- Series: I/A Series DCS
- Core Function: Provides a secure, vibration-resistant field wiring interface for the FBM201 8-channel analog input module.
- Product Type: Compression Field Terminal Module
- Key Specs: Compression Wiring, Multi-channel Analog, FBM201 Compatible
- Condition: New Original (New Surplus)
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Compression Field Terminal Module |
| System Compatibility | FOXBORO I/A Series DCS |
| Companion Module | FBM201 (8-Channel 0-20mA AI) |
| Wiring Style | Compression Terminals |
| Primary Function | Field Signal to Control System Interface |
| Mounting | Control Cabinet / Field Junction Box |
| Compliance | FOXBORO I/A Series Standard |
FOXBORO P0916AA
Product Introduction
Field wiring reliability is critical for maintaining accurate analog signal acquisition in continuous processes. The is a compression-type field terminal module designed specifically for the I/A Series distributed control system. It serves as the physical interface between field instruments and the FBM201 functional module, ensuring that critical 0-20mA analog signals are safely and reliably routed into the control system.
Unlike traditional screw terminals, this module utilizes a compression terminal design that provides superior resistance to vibration and prevents loosening over time. Field technicians value this exact specification because the clear terminal layout and robust construction significantly reduce installation time and eliminate the risk of intermittent signal connections in harsh industrial environments.
Key Selling Points & Differentiators
- Exact FBM201 Compatibility: Designed specifically as the field wiring unit for the FOXBORO 8-channel analog input module; not recommended for other FBM types due to pinout and mechanical differences.
- Vibration-Resistant Compression Terminals: Utilizes compression-style wiring that maintains secure connections in high-vibration environments, drastically reducing maintenance callbacks for loose wires.
- Clear Circuit Identification: Features an intuitive terminal layout that allows field personnel to quickly identify and wire analog transmitter loops, streamlining commissioning and troubleshooting.
- Rigorous Live Bench Testing: Every unit undergoes point-to-point continuity checks, insulation resistance testing, and mechanical torque verification before shipping.
- New Surplus Availability: Factory-sealed condition with verified source traceability, bypassing typical OEM lead times for discontinued I/A Series hardware.
- Anti-Counterfeit Verification: Serial numbers are checked against manufacturer databases during incoming inspection to guarantee authenticity.
FOXBORO P0916AA
FAQ
No. The is specifically designed for the (8-channel 0-20mA analog input). Modules like the FBM202 (thermocouple) or FBM203 (RTD) require different terminal assemblies due to varying pin configurations and signal conditioning requirements. Always match the terminal module to the exact FBM part number.
Yes, upgrading to the compression terminal module is highly recommended for high-vibration areas. However, you must verify that the field cabling is compatible with the compression lug style and that the overall physical dimensions fit your existing junction box or control cabinet layout.
Do I need to configure anything in the control strategy for this terminal module?
No. The is a passive wiring interface with no active electronics or firmware. All signal scaling, filtering, and fault detection are configured in the I/A Series control builder for the companion module.
What happens if I overtighten the compression terminals?
While compression terminals are designed to be more forgiving than screw terminals, overtightening can still damage the internal clamping mechanism or strip the threads. Always use a calibrated torque screwdriver and follow the manufacturer’s specified torque values to ensure a gas-tight connection without mechanical damage.
Is there a warranty on this new surplus unit?
Yes. All new surplus modules come with a standard 12-month functional warranty. If the unit fails during normal operation within that period, we provide a direct replacement. We also include our internal test report with every shipment so you can verify the continuity and mechanical test results before installation.
