Product Core Brief
- Model: 330104-00-22-10-02-05
- Brand: BENTLY
- Series: 3300 XL 8mm M10 Forward Mount Armored Proximity Transducer Line
- Core Function: Captures radial shaft vibration, static thrust offset, and Keyphasor speed pulses via deep metric front counterbores on compressors and turbines.
- Product Type: Factory integrated single-piece armored proximity probe assembly
- Key Specs: 1 m armored 50 Ω triaxial cable | 2.2 in stainless steel housing | ATEX/IECEx/CSA global hazardous location certifications
- Condition: New Original (New Surplus)
Product Introduction
The BENTLY 330104-00-22-10-02-05 is a metric armored forward-mount eddy-current probe built for deep counterbore bearing housings where short unarmored probes sustain rapid cable abrasion. It outputs calibrated linear gap voltage signals for safety-rated turbomachinery protection loops.This unit uses a 2.2 in stainless steel housing with integral stainless braided armor, cutting field cable replacement frequency by roughly 70% versus unarmored M10 probes of matching thread spec. Its FluidLoc molded joint reduces oil-wicking induced measurement drift by roughly 90% in high-temperature turbine lube enclosures—though your mileage may vary with unfiltered synthetic turbine lubricants.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Mount Thread | M10×1 metric fine thread, standard forward front-install design |
| Unthreaded Tip Length | 0.0 in fully threaded PPS insulated sensing tip (suffix 00 code) |
| Probe Housing Length | 2.2 in (55.9 mm) AISI 304 stainless steel extended body (suffix 22 code) |
| Factory Integrated Cable Length | 1.0 m 50 Ω triaxial FEP stainless armored wire (suffix 10 code) |
| Standard Linear Sensitivity | 7.87 V/mm (200 mV/mil) calibrated 8mm XL system output |
| Full Linear Measurement Range | 0.25 mm to 2.3 mm; factory recommended installation gap 1.27 mm midpoint |
| Operating Temp (Probe Tip) | -52 °C to +177 °C continuous process exposure |
| Operating Temp (Cable) | -45 °C to +100 °C cabinet ambient air |
| Connector Hardware | Mini gold-plated ClickLoc tool-free lockable male fitting (suffix 02 code) |
| Official Certifications | API 670 Rev 4, SIL 2, ATEX/IECEx Zone 2, CSA Class I Div 2 intrinsic safety (suffix 05 code) |
| Minimum Metallic Target Diameter | 15.2 mm flat steel target surface |
| Max Safe Axial Tensile Load | 330 N without molded joint separation or internal conductor breakage |
Quality Control Process (Engineer’s Perspective)
- Incoming Verification: Cross-reference serial numbers against OEM production logs, scan factory anti-counterfeit QR labels, inspect armored cable for fraying, extended housing for bending dents, cracked PPS tips, or split FEP cable outer jackets.
- Live Functional Test: Mate the unit to a calibrated 330180-XX-05 global certified Proximitor, supply 24 V DC input, run a 26 hour continuous load cycle with ambient temperature logged every 15 minutes.
- Electrical Parameter Test: Apply 500 V Megger insulation sweep; pass threshold reads >10 MΩ between triaxial conductors and outer shielding layer.
- Firmware Verification: Well, technically this passive probe contains no firmware, but record paired Proximitor firmware revision and photograph full ClickLoc connector lock engagement seating.
- Final QC & Packaging: Wipe assembly with anti-static isopropyl wipe, seal inside shielding ESD bag, affix printed QC Passed sticker stamped with exact test completion date.
Replacement Pitfall Guide
❗ Firmware Mismatch: 3500 rack firmware Revision F cannot fully compensate capacitance drift for 1-meter 8mm transducer stacks. Always upgrade rack monitor modules to Revision G before physical installation.❗ DIP Switch / Jumper Misconfiguration: Stock 330180 Proximitor factory default system length setting reads 5 m, not the unit’s 1 m total cable length; incorrect values create permanent static offset in thrust position trending data.❗ Terminal / Cable Incompatibility: Do not pair with 75 Ω NSv extension cables; mismatched coaxial impedance distorts high-frequency small-shaft vibration waveforms and triggers constant channel fault flags.❗ Power Supply Mismatch: Each full transducer stack draws 120 mA at 24 V DC; calculate total rack power draw with a mandatory 20% load headroom to avoid undervoltage trips during equipment startup transients.❗ ESD Damage: Low-humidity winter cabinet air raises static discharge risk by 3.8x. Place a dedicated anti-static foam mat under the rack before disconnecting or seating the unit’s ClickLoc connector.Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- 330104-00-22-10-02-05 → 330180-XX-05 Global Certified 8mm Proximitor : Direct — 50 Ω 8mm XL impedance match, zero adapter hardware required
- 330104-00-22-10-02-05 → 330980 NSv Proximitor : Incompatible — 75 Ω NSv circuits cannot calibrate the 8mm wide linear measurement span
- 330104-00-22-10-02-05 → 330104-00-22-10-02-00 : Needs Adaptation — Uncertified non-hazardous variant, extra safety documentation mandatory for classified plant acceptance
Benchmarks
- Signal response rise time: 1.2 μs (simulated 0.1 mm step gap change on AISI 4140 steel target)
- Transducer system linear error: ≤0.21% full span (24 V DC supply, 25 °C controlled ambient)
- Connector lock cycle durability: 1,000 mate/unmate cycles with no impedance shift exceeding 0.11 Ω
