Product Core Brief
- Model: 330180-51-00
- Brand: Bently Nevada
- Series: 3300 XL
- Integration Role: Conditions eddy current signals for vibration monitoring systems.
- Product Type: Proximity Transducer
- Key Specs: 5.0m System Length | DIN Rail Mount | 7.87mV/µm
- Note: Condition: New Original (New Surplus).
Key Technical Specifications
| Parameter | Value |
|---|---|
| System Length | 5.0 meters (16.4 feet) |
| Mounting Style | DIN Rail |
| Sensitivity | 7.87 mV/µm (200 mV/mil) |
| Input Type | Non-contact Eddy Current |
| Compatible Probes | 3300 XL Series |
| Supply Voltage | -24 VDC Nominal |
| Output Signal | Analog Voltage/Current |
| Frequency Response | 0–10 kHz (Standard) |
| Operating Temp | -40°C to +85°C |
| Approval Code | 00 (Standard) |
Product Introduction
The 330180-51-00 is a proximity transducer for the 3300 XL system. It converts probe gap data into standard signals for monitoring.
Integrators select this unit for its 7.87mV/µm sensitivity. This precision ensures reliable trip logic during transient machine events.
Wiring & Backplane Integration Notes
Verify cable impedance matches the 330180-51-00 specification exactly. Mismatched extension cables cause signal attenuation.
Total system length must equal 5.0 meters. This includes probe, extension, and transducer internal lengths.
Grounding loops are the primary failure mode here. Use single-point grounding at the transducer DIN rail. Never ground both ends of the shield.
Clean connectors with approved solvent before mating. Oil contamination creates high-resistance joints that mimic vibration faults.
Integrator’s FAQ
1. Can I hot-swap this transducer while the monitor is powered?
No. The 330180-51-00 lacks internal isolation for live insertion. Power down the channel to prevent transient spikes from damaging the monitor’s input stage.
2. Is this model still supported or is there a successor?
This remains a primary part for 3300 XL systems. For newer 3500 frameworks, verify compatibility with OEM documentation before substituting.
3. Will swapping this unit erase my monitor’s configuration?
No. Configuration resides in the monitor module, not the transducer. However, you must recalibrate the gap voltage after physical replacement.
4. What warranty applies to New Surplus versus refurbished?
New Surplus units carry a full 12-month functional warranty. Refurbished parts often have aged electrolytic capacitors and carry only 30-day coverage.
5. Why is pricing lower than OEM direct but safe for critical use?
New Surplus inventory is excess factory stock, not returned field units. You avoid the hidden downtime costs of refurbished components with unknown service history.
