Product Core Brief

• Model: CC-PCF901 (51405047-175)
• Brand: Honeywell
• Series: Experion PKS / C-Series
• Core Function: Distributes FTE (Fault Tolerant Ethernet) cables to multiple C-Series FIMs and cabinet network nodes.
• Product Type: FTE Control Firewall / Distribution Module
• Key Specs: FTE Distribution | C300 Compatible | 24 VDC | CF9 IOTA Mount
• Condition: New Original (New Surplus)

Product Introduction

The is a critical network infrastructure module for the Experion PKS C-Series architecture. It acts as an FTE (Fault Tolerant Ethernet) control firewall and distribution hub, efficiently routing FTE network traffic to multiple Series C Fieldbus Interface Modules (FIMs) and in-cabinet network nodes like C300 controllers.

Designed for high-availability environments, this module mounts directly onto a CF9 Input/Output Termination Assembly (IOTA). It ensures deterministic communication and network isolation, protecting the control layer from unauthorized access and maintaining system integrity even during network faults.

Key Technical Specifications

Quality Control Process (Engineer’s Perspective)

We don’t just box these and ship them. Here is our actual bench test workflow.

1. Incoming Verification: We verify the serial number (51405047-175) against Honeywell’s traceability records. A visual inspection checks for bent pins on the CF9 IOTA connector and ensures the FTE port latches are intact.
2. Live Functional Test: We mount the unit on a live CF9 IOTA in a C300 test rack. We verify FTE ring redundancy by simulating a cable break and confirming traffic reroutes within the <300 ms specification.
3. Electrical Parameter Test: We measure the 24 VDC current draw to ensure it stays within the 0.112A nominal spec. Ground continuity to the IOTA chassis is verified.
4. Firmware Verification: We read the module’s internal firmware revision via the FTE management interface. We photograph any hardware revision stickers to ensure compatibility with the target C300 controller.
5. Final QC & Packaging: The module is sealed in an anti-static bag with silica gel. A QC sticker showing the test date and technician initials is applied to the exterior.

Replacement Pitfall Guide

Field replacements on FTE networks are unforgiving. Watch out for these traps.

1. Firmware Mismatch: ❗ Critical. A brand-new might have a newer firmware revision than your existing CPU or FTE switch. The Experion controller may flag a configuration mismatch or fail to join the FTE ring. Always check your system’s allowed firmware matrix before installing.
2. IOTA Base Compatibility: This module must be mounted on a CF9 IOTA base. Attempting to install it on a standard C-Series IOTA (like CC-TAIX11) will cause physical damage and electrical faults.
3. FTE Ring Topology: Verify the FTE cable connections (A and B channels) before powering up. Reversed channels or a missing termination resistor will prevent the module from joining the redundant ring, causing network faults.
4. Power Supply Mismatch: Verify your 24 VDC field power supply has adequate headroom. While this module draws only ~0.112A, a fully populated CF9 IOTA with multiple FIMs can create significant cumulative load.
5. ESD Damage: FTE interface chips are highly sensitive to electrostatic discharge. Always wear a grounded wrist strap when handling the bare PCB. I’ve seen modules fail bench testing because they were handled on a dry winter day without protection.

Keep these in mind and you’ll cut 90% of rework time.

Compatibility Matrix & Benchmarks

Compatibility

• Honeywell CC- Rev A → CC- Rev B : Direct Replacement — Verify firmware compatibility with CPU.
• Honeywell CC- 51405047-175 → CC- : Direct Replacement — Same module, OEM part number format.

Benchmarks

• FTE Ring Switchover: < 300 ms (zero process interruption during single cable failure)
• Network Join Time: < 5 s (from power-up to active FTE node status)

Need the FTE ring topology diagram for the ? I can pull up the cabling schematic showing the A/B channel routing and termination points for the CF9 IOTA.
