Product Core Brief
- Model: DS200SDCCG1AGD
- Brand: GE (General Electric)
- Series: Mark V / Speedtronic / DS200
- Core Function: Serves as the main drive controller for GE DC/AC/EX2000 systems, executing complex control algorithms and managing drive signals.
- Product Type: Drive Control Board / Main Controller
- Key Specs: Triple Microprocessor, Shared RAM, 10-LED Diagnostic Array
- Condition: New Original (New Surplus)
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Drive Control Board (Main Controller) |
| System Compatibility | GE Mark V, DC2000, AC2000, EX2000 |
| Processing Architecture | 3 Microprocessors with Shared RAM |
| Diagnostic Interface | 10-LED Status Array |
| Control Modes | Speed, Position, Torque Control |
| Communication Protocols | Ethernet, RS-232, RS-485 |
| Protection Features | Over-voltage, Over-current, Over-temperature |
| Operating Temp | -40°C to 70°C |
GE DS200VPBLG2A
Product Introduction
Reliable and high-speed processing is the backbone of GE’s heavy-duty drive and excitation systems. The is the main drive control board for the Mark V and DS200 series platforms. Engineered to handle the rigorous demands of industrial power conversion, it utilizes a powerful triple-microprocessor architecture with shared RAM to simultaneously execute complex control algorithms, manage drive signal outputs, and communicate with other system components.
Field engineers rely on the because its advanced onboard diagnostics and deterministic processing ensure precise motor control and rapid fault detection. Whether regulating a gas turbine exciter or managing a variable speed drive in a steel mill, this board provides the high-availability performance required to keep critical processes running.
Key Selling Points & Differentiators
- Triple Microprocessor Architecture: Features three microprocessors with shared RAM for simultaneous processing, ensuring high-speed loop control and system redundancy; not recommended for non-GE drive platforms.
- Advanced Onboard Diagnostics: Equipped with a 10-LED diagnostic array that displays fault codes or sequential “heartbeat” patterns, allowing technicians to quickly troubleshoot without external laptops.
- Versatile Control Capabilities: Supports multiple control modes (speed, position, torque) and communication protocols (Ethernet, RS-232, RS-485) for seamless integration into legacy and modern plant networks.
- Rigorous Live Bench Testing: Every unit undergoes a 24-hour continuous load test with microprocessor stress testing and LED diagnostic verification before shipping.
- New Surplus Availability: Factory-sealed condition with verified source traceability, bypassing typical OEM lead times for discontinued Mark V hardware.
- Anti-Counterfeit Verification: Serial numbers are checked against manufacturer databases during incoming inspection to guarantee authenticity.
GE DS200VPBLG2A
FAQ
Yes, the is designed specifically for the GE Mark V Speedtronic platform and related DC2000/AC2000/EX2000 drive systems. Always verify your system’s exact hardware revision and backplane configuration before ordering to ensure drop-in compatibility.
I have a DS200SDCCG1AHD on hand. Can I use it as a direct replacement?
The suffix (G1AGD vs. AHD) indicates specific hardware revisions, firmware versions, or factory calibration parameters. While they share the same triple-processor architecture, substituting a different suffix without verifying the exact control parameters can result in communication mismatches or improper drive regulation. Always match the exact part number.
How do I read the diagnostic LEDs on this board?
The board features 10 LEDs arranged in a row. Under normal, fault-free operation, two LEDs will sequentially illuminate from left to right as a “heartbeat.” If a trigger fault occurs, the LEDs will display a specific binary fault code. Safety Warning: Always exercise extreme caution when opening the cabinet, as high voltage is present. Never touch internal components while the drive is energized.
Do I need to configure the control parameters before installing?
Yes. The board requires configuration parameters to define how it processes information and controls the drive. This is typically done using GE’s proprietary software tools via a laptop connection. If replacing a failed board, you may need to transfer the configuration or download a saved profile to match the existing system setup.
Is there a warranty on this new surplus unit?
Yes. All new surplus modules come with a standard 12-month functional warranty. If the unit fails during normal operation within that period, we provide a direct replacement. We also include our internal test report with every shipment so you can verify the 24-hour load test and processor communication results before installation.
