Product Core Brief
- Model: DS200SDCCG1AFD
- Brand: GE (General Electric)
- Series: GE DS200 Series / Speedtronic Mark V
- Core Function: Serves as the central drive control processor executing core algorithms, managing data, and coordinating system I/O for industrial drives and turbines.
- Product Type: Drive Control Board (SDCC) / Central Processing Module
- Key Specs: Triple Microprocessor Architecture | VME Backplane | Part Number
- Condition: New Original (New Surplus) | Factory Sealed
Key Technical Specifications
| Parameter | Value |
|---|---|
| Component Type | Central Drive Control Board (SDCC) |
| System Platform | GE DC2000 / AC2000 / EX2000 / Mark V |
| Processor Architecture | Triple Microprocessor with Shared RAM |
| Diagnostic Interface | 10-LED Status & Fault Code Array |
| Communication | GE DLAN+ (Proprietary Drive LAN) / VME Backplane |
| Manufacturer Part Number | |
| Installation Method | Plug-in Board with Standoffs & Ribbon Cables |
| Application | Heavy-Duty Process Lines, Turbines, Rolling Mills |
| Environmental Rating | Industrial Grade, Conformal Coated |
| Condition | New Original (New Surplus) |
| Warranty | 1-Year Functional Warranty |
GE DS200SDCCG1AFD
Product Introduction
Maintaining deterministic control in heavy-duty industrial applications requires a highly reliable central processor, and the is engineered to serve as the brain of your GE drive or turbine system. Functioning as the central Drive Control Board (SDCC), this module coordinates complex operations for GE DC2000, AC2000, and EX2000 platforms, as well as Speedtronic Mark V control panels.
Designed for continuous industrial duty, the features a robust triple-microprocessor architecture with shared RAM, ensuring redundant processing and fault tolerance. It communicates seamlessly with companion boards (like the DSPC and DCFB) via the VME backplane and ribbon cables, managing everything from current/voltage loop algorithms to system-wide diagnostics.
Key Selling Points & Differentiators
- Triple Microprocessor Redundancy: Utilizes three microprocessors with shared RAM to execute core control algorithms reliably, minimizing the risk of single-point processor failures.
- Comprehensive Onboard Diagnostics: Features a 10-LED diagnostic array that visually displays fault codes or normal operational sweeps, allowing technicians to quickly identify issues without external laptops.
- Verified Functionality: Every undergoes a 24-hour live load test on a dedicated GE drive test rack before shipping, complete with a signed test report.
- Not Recommended For: Do not use this board as a standalone controller or in non-GE DS200 ecosystem racks. It requires specific backplane power (+5VDC, ±15VDC) and companion I/O boards.
- Stock Availability: Current inventory is factory-sealed new surplus with traceable lot numbers; typically ships within 48 hours of order confirmation.
- Warranty Backed: Includes a 1-year functional warranty covering manufacturing defects and DOA conditions, with no restocking fees for verified failures.
GE DS200SDCCG1AFD
FAQ
Yes. All units in stock have passed our 24-hour live bench test and include a signed test report. We ship same-day for orders placed before 2 PM EST, so you’ll have tracking before end of day.
The is designed for GE DC2000, AC2000, EX2000, and Mark V systems. As a drop-in replacement, it maintains form/fit/function compatibility with the DS200 H1 family. Always verify your system BOM and companion board revisions before ordering.
How do I read the diagnostic LEDs on this board?
The board features 10 LEDs in a row. During normal operation, two LEDs sweep from left to right. If a fault occurs, all 10 LEDs illuminate to display a specific binary fault code. Safety Warning: Always ensure the cabinet is powered down and capacitors are discharged before opening the door to read the LEDs.
Do I need to reconfigure the module after installation?
Configuration parameters are typically managed via GE software tools connected to a laptop. If replacing a failed board, you may need to transfer firmware/EPROMs from the legacy board or download the system configuration to the new SDCC.
What if the module fails within the warranty period?
We offer a no-questions-asked replacement for any verified manufacturing defect. Ship the failed unit back with your RMA number, and we’ll send a replacement within 24 hours of receipt. We also provide a loaner program for critical drive applications to minimize downtime.
Can this board handle high-interference environments?
Yes. The features conformal coating and is designed for ventilated control cabinets. However, ensure ribbon cables are evenly tightened and standoffs are secure, as vibration-induced connector oxidation is a common cause of intermittent faults.
Is this a refurbished or new surplus unit?
This is New Original (New Surplus) – factory sealed, never installed, with full traceability to the original manufacturing lot. It is not refurbished, repaired, or pulled from a decommissioned system. We provide the original manufacturer’s lot code upon request for your quality records.
Quality Transparency SOP
- Incoming Verification: Source traceability confirmed via lot code; anti-counterfeit visual inspection; serial number cross-referenced with OEM records; accessories verified.
- Live Bench Test: Dedicated GE drive test rack; power-on self-check; VME backplane communication handshake; LED diagnostic sweep validation; 24-hour continuous load test; signed test report generated.
- Electrical Tests: Insulation resistance verified at 500V megger (>10 MΩ); ground continuity confirmed; backplane power rail stability validated.
- Firmware Verification: Firmware/EPROM revision recorded; configuration parameters backed up and documented.
- Final QC & Packaging: QC sign-off; anti-static seal applied; shock protection installed; QC Passed label affixed with date and inspector ID.
Test photos and video available upon request. We never claim “100% failure-free” – we provide verified, tested units with documented performance.
Technical Risk Avoidance
- High Voltage Hazard: Risk: Severe injury or board damage. Prevention: Never touch components while the VFD/drive is energized. Field Note: The SDCC processes high-voltage logic. Always discharge capacitors and verify 0V before opening the cabinet.
- Ribbon Cable Seating: Risk: Intermittent communication or false faults. Prevention: Ensure all ribbon cables are fully seated and standoffs are evenly tightened. Field Note: A slightly tilted ribbon connector caused intermittent “missing phase” alarms during plant vibration. Push firmly and secure.
- Firmware Mismatch: Risk: System fails to boot or erratic control. Prevention: Verify the EPROM/firmware revision matches the host system requirements. Field Note: Swapping an SDCC without matching the firmware revision caused the drive to trip on load changes. Always check the revision.
- Configuration Loss: Risk: Drive fails to regulate motor. Prevention: Download the correct configuration parameters to the new board. Field Note: A blank SDCC installed without parameters caused the motor to run uncontrollably. Always have the config file ready.
- ESD Damage: Risk: Silent microprocessor failure. Prevention: Use grounded wrist strap and anti-static mat during handling. Field Note: We’ve tested boards that passed power-on but had corrupted shared RAM after 48 hours due to ESD. Handle with care.
