Product Core Brief
- Model: P0916AJ
- Brand: Foxboro (Invensys / Schneider Electric)
- Series: I/A Series Distributed Control System (DCS)
- Core Function: Provides a secure, vibration-resistant physical interface for routing 8-channel analog field signals into the FBM203 module.
- Product Type: Compression Terminal Assembly (TA) / Wiring Block
- Key Specs: FBM203 Compatible | 8-Channel Analog Input | Part Number
- Condition: New Original (New Surplus) | Factory Sealed
Key Technical Specifications
| Parameter | Value |
|---|---|
| Component Type | Compression Terminal Assembly (TA) |
| System Platform | Foxboro I/A Series DCS |
| Compatible FBM | FBM203 (8-Channel Analog Input) |
| Connection Method | Compression / Spring-Loaded |
| Channel Count | 8 Independent Signal Connections |
| Manufacturer Part Number | |
| Mounting | Front-Mount Plug-in on FBM203 |
| Application | Field Wiring Interface for AI Signals |
| Environmental Rating | Industrial Grade, Vibration Resistant |
| Condition | New Original (New Surplus) |
| Warranty | 1-Year Functional Warranty |
FOXBORO P0916AJ
Product Introduction
Field wiring failures in analog loops are almost always traced back to loose screw terminals, which is why the utilizes a compression-style connection. Designed specifically for the 8-channel analog input module, this terminal assembly provides a gas-tight, vibration-proof mechanical interface for field sensors.
Engineered for harsh industrial environments, the eliminates the need for periodic retorquing while maintaining precise signal integrity. By replacing traditional screw-down clamps with a uniform compression mechanism, this component ensures consistent contact pressure across all 8 channels, significantly reducing commissioning time and preventing intermittent signal loss during plant vibration.
Key Selling Points & Differentiators
- Vibration-Proof Compression Design: Utilizes spring-loaded compression technology rather than traditional screws, ensuring gas-tight connections that will not back out in high-vibration turbine or compressor areas.
- Precision-molded for the 8-channel analog input module, guaranteeing exact pin alignment and preventing cross-wiring during field installation.
- Verified Functionality: Every undergoes mechanical fit validation and continuity testing before shipping, complete with a signed test report.
- Not Recommended For: Do not use this terminal assembly with FBM201, FBM204, or discrete I/O modules. The pinout and compression depth are specific to the analog input card.
- Stock Availability: Current inventory is factory-sealed new surplus with traceable lot numbers; typically ships within 48 hours of order confirmation.
- Warranty Backed: Includes a 1-year functional warranty covering manufacturing defects and DOA conditions, with no restocking fees for verified failures.
FOXBORO P0916AJ
FAQ
Yes. All units in stock have passed our mechanical fit and continuity tests. We ship same-day for orders placed before 2 PM EST, so you’ll have tracking before end of day.
No. The is specifically designed for the analog input module. Using it on an FBM201 will result in improper pin alignment and potential damage to the field wiring. Always verify the FBM model number before ordering.
Do I need a special tool to install this terminal assembly?
Yes. Compression terminal assemblies require the specific Foxboro compression tool to ensure proper seating and contact pressure. Using pliers or improvised tools can damage the internal spring mechanism.
What if the terminal assembly fails within the warranty period?
We offer a no-questions-asked replacement for any verified manufacturing defect. Ship the failed unit back with your RMA number, and we’ll send a replacement within 24 hours of receipt.
Can this terminal handle high-interference environments?
Yes. The maintains consistent contact pressure that prevents micro-arcing and signal noise. However, ensure your field wiring uses properly shielded twisted-pair cable with correct grounding at the baseplate end.
Is this a refurbished or new surplus unit?
This is New Original (New Surplus) – factory sealed, never installed, with full traceability to the original manufacturing lot. It is not refurbished, repaired, or pulled from a decommissioned system. We provide the original manufacturer’s lot code upon request for your quality records.
Quality Transparency SOP
- Incoming Verification: Source traceability confirmed via lot code; anti-counterfeit visual inspection; serial number cross-referenced with OEM records; accessories verified.
- Live Bench Test: Dedicated test bench; mechanical fit validation with ; compression terminal continuity test; insulation resistance verification; signed test report generated.
- Electrical Tests: Insulation resistance verified at 500V megger (>10 MΩ); ground continuity confirmed; channel-to-channel contact resistance validated.
- Firmware Verification: N/A (Passive mechanical component).
- Final QC & Packaging: QC sign-off; anti-static seal applied; shock protection installed; QC Passed label affixed with date and inspector ID.
Test photos and video available upon request. We never claim “100% failure-free” – we provide verified, tested units with documented performance.
Technical Risk Avoidance
- FBM Model Mismatch: Risk: Mechanical incompatibility or pin damage. Prevention: Verify you are using this TA specifically with an module. Field Note: We’ve seen customers order the wrong TA because and FBM204 use different terminal assemblies. Always verify the FBM model.
- Improper Compression Tool: Risk: Poor connections or internal damage. Prevention: Use only the specified Foxboro compression tool. Field Note: Using an incorrect crimp tool caused intermittent signal failures that mimicked a bad FBM. Use the correct tool.
- Wire Size Mismatch: Risk: Loose or damaged connections. Prevention: Verify field wire gauge matches the terminal assembly specifications. Field Note: Oversized wires damaged the compression terminals during installation. Check wire size first.
- Missing Locking Mechanism: Risk: TA dislodged during vibration. Prevention: Ensure the TA is fully seated and locked onto the FBM. Field Note: A partially locked TA fell off during plant vibration. Push firmly until the latch clicks.
- ESD Damage: Risk: Damage to FBM during TA installation. Prevention: Use grounded wrist strap when handling FBM and TA. Field Note: Static discharge during TA installation damaged the FBM input circuits. Handle with care.
