Product Core Brief
- Model: KJ4001X1-CC1 (12P0733X032 internal PN)
- Brand: Emerson
- Series: DeltaV M-Series DCS
- Core Function: Provides 4-wire field device interface for analog/digital I/O cards
- Product Type: I/O Terminal Block
- Key Specs: 16 terminals (8 channels) | 30VDC/2A per channel | 1500VDC isolation
Key Technical Specifications
- Part Number: (12P0733X032)
- Wiring Configuration: 4-wire per channel (2×signal, 2×power/return)
- Terminal Count: 16 terminals supporting 8 channels
- Voltage/Current Rating: 30VDC, 2A per channel
- Isolation: 1500VDC between field and system sides
- Wire Gauge: 2.5 mm² max, screw-type terminals
- Dimensions (W×H×D): 120 × 72 × 26 mm
- Weight: 0.09 kg
- Operating Temp: –40°C to +85°C
- Certifications: CE, UL, RoHS, Zone 2/Class I Div. 2 hazardous area rated
- Mounting: Snaps onto DeltaV I/O carrier (e.g., KJ4101X1-BA1)
Product Introduction
The is a 4-wire I/O terminal block built exclusively for Emerson DeltaV M-Series systems. It connects 4-wire field devices (4–20mA transmitters, powered sensors) to DeltaV I/O cards via a direct snap-on interface.This unit integrates dedicated shielding grounding to suppress EMI/RFI interference. It reduces wiring errors with clearly labeled terminals and supports fast, tool-less installation on standard carriers.
